This command sets the configuration type of the digital outputs onto the different
I/O-BOX devices.
Parameter description
<ib_div_ndex>
A number from
could specify an index value of an I/O-BOX device that is already connected to
the MAMBOII. The <ib_div_ndex> index should correspond to one of the
<cnf_ib_div_index> indexes that you have assigned on the I/O-BOX configuration
setting.
<o_index>
Identifies the output index of the I/O-BOX device to be configured. It can be set
to a value from
respectively. Pin designations for the 16-pin MOLEX connector of the I/O-BOX are
shown in chapter 6.10.3.
<config_type>
Configures settings related to the selected output. It can be set to:
Value
high
low
hpulse,<high_time>
3.2.8.2.2
Command syntax
Examples
Responses
Command description
This command serves to change the operation modes of the I/O-BOX devices. With
this command you can put an I/O-BOX into SLEEP mode for a predefined length of
time. By default, each I/O-BOX runs in continuous mode.
Parameter description
<ib_div_ndex>
A number from
could specify an index value of an I/O-BOX device that is already connected to
