3.2.25.1.1.3 DISPLAY (DISPLAY states and events)

3.2.25.1.1.3.1
STATES-are checked every second
None
EVENTS-are evaluated just when the event occurs
Event notification code
DISPLAY.DIALOG.e<id>=<btn>
<id>
<btn>
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

DISPLAY.DIALOG (DIALOG states and events)

Meaning
Occurs when a specific dialog box opens and the user presses either on the left or
right option or the time out expires.
Identifies which dialog box caused a specific button event. It can be set to a value
in range 0 to 99.
Identifies which button (option) contained on the dialog box the pressed. It can be
set to:
btn1
bnt2
inactive the timeout specified for that dialog box has expired
Table 25: Display states and events.
2.4.0_ -
EVISION BETA
the left button (option) is pressed.
the right button (option) is pressed.
