FALCOM MAMBOII User Manual page 244

C C
ONFIGURATION OMMAND
Lon
Alt
Speed
Course
DOP
SatsUsed
Fix
NavDist
PosDist<storage_index>
GFName<ID>
GF<ID>
AreaName<ID>
Area<ID>
LastGF
LastGFName
LastGFState
LastArea
LastAreaName
LastAreaState
GSM
IMEI
SIMID
OwnNumber
OperatorID
Operator
CallerNumber
Fieldstrength
CID
LAC
Call
SMSNumber
SMSText
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
Used to report the current GPS longitude value in decimal degrees.
Used to report the current GPS altitude value in meters.
Used to report the current GPS velocity value in meters/second
Used to report the current course over ground, indicating the current direction of the
MAMBOII device.
Used to report the current DOP value (GPS position accuracy error) of the device.
Used to report the number of satellites that currently are in use.
Used to report whether or not the MAMBOII device has already got a valid GPS-Fix. If
system MAMBOII has already got a valid GPS-Fix, the return value is 1, otherwise 0.
Used to report the actual distance in meters since the device has left a known start
point.
Used to report the actual distance in meters between a stored point and current location
of the device. The <storage_index> specifies a storage index in the range of 0 to 4.
Used to report the name of a configured Geofence. The <ID> specifies the ID-number of
a Geofence. Up to 100 Geofences are available for use, but it depends on which indices
are already putted in use. It can be set to a value from 0 to 99.
Used to report the current state of the selected Geofence. The <ID> specifies the ID-
number of a Geofence. Up to 100 Geofences are available for use, but it depends on
which indices are already putted in use. It can be set to a value from 0 to 99.
Used to report the name of a configured Geofence area. The <ID> specifies the ID-
number of an area. Up to 32 Geofencing areas are available for use, but it depends on
which indices are already putted in use. It can be set to a value from 0 to 31.
Used to report the current state of the selected Geofence area. The <ID> specifies the
ID-number of an area. Up to 32 Geofencing areas are available for use, but it depends
on which indices are already putted in use It can be set to a value from 0 to 31.
Used to report the Geofence identification number <id> on which the last event has been
occurred. "none" is reported if no GF event has been occurred before.
Used to report the Geofence name on which the last geofence event has been occurred.
"none" is reported if no GF event has been occurred before.
Used to report the Geofence state (inside -1 or outside -0) on which the last event has
been occurred. "none" is reported
Used to report the Area identification number <id> on which the last event has been
occurred. "none" is reported
Used to report the Area name on which the last event has been occurred. "none" is
reported if no AREA event has been occurred before.
Used to report the Area state (inside -1 or outside -0) on which the last event has been
occurred. "none" is reported, if no AREA event has been occurred before.
Used to report the current IMEI number of the device
Used to report the mobile subscriber ID from the used SIM
Used to report the GSM phone number of the device
Used to report the currently used GSM operator ID.
Used to report the current GSM operator name used by the device
Used to report the phone number of the currently incoming call. The incoming call may
be established, but after it is finished, no caller number will be transmitted (an error will
be delivered instead)
Used to report the field strength of the currently used GSM cell
Used to report the currently used GSM cell ID
Used to report the currently used GSM local area code
Used to report the state of incoming calls.
Possible values may be retrieved:
-idle
-incoming voice call (ring:3)
-incoming data call (ring:1)
-inside incoming voice call
-establish data call
-inside data call
-outgoing ring
-inside outgoing. voice call
Used to retrive/report the phone number of the last incoming SMS. No value will be
shown if there was no SMS received after the system has been started.
Used to request the text of last incoming SMS. No value will be shown if there was no
SMS received after the system has been started.
2.4.0_ -
EVISION BETA
i
f no GF event has been occurred before.
i
f no AREA event has been occurred before.
V 1.0.0
ERSION
Page 244 of 271
