3.2 PFAL Commands

The following table provides a complete list of the PFAL commands used to
manage/administrate different parts of an application built on the MAMBOII system.
Please note that, the PFAL commands listed in the table below could not be sent to the target
device in that form. Information about each command can be found on the respective
reference chapter and page. Use the hypertext links (shown in blue text) to navigate the
chapter/sections. Each chapter describes the tasks each command performs, how command
settings can be defined etc.
Please note that, only straight double quotation marks (" ") should be used within PFAL
commands, configuration parameters, etc.
As this documentation has been created using Microsoft Word, some straight quotation
marks might have been transformed to the right and left smart (curly) quotation marks,
which won't be accepted by the device.
PFAL COMMAND SET
System commands
$PFAL,Sys.Security.Lock,"password"
$PFAL,Sys.Security.Unlock,"password"
$PFAL,Sys.Security.RemoveLock,"password"
$PFAL,Sys.RUpdate.Init
$PFAL,Sys.RUpdate.DataMode
$PFAL,Sys.RUpdate.Finish
$PFAL,Sys.Device.Reset
$PFAL,Sys.Device.Update
$PFAL,Sys.Device.Shutdown
$PFAL,Sys.Device.FactoryReset
$PFAL,Sys.Device.Sleep=<value>
$PFAL,Sys.Device.ClearAlarm
$PFAL,Sys.Device.ClearConfig
$PFAL,Sys.Device.CfgUpdateMode
$PFAL,Sys.Timer<index>.Configure=<mode>,<timeout>
$PFAL,Sys.Timer<index>.Start=<timer_settings>
$PFAL,Sys.Timer<index>.Stop
$PFAL,Sys.Timer<index>.Pause
$PFAL,Sys.Timer<index>.Resume
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
2.4.0_ -
EVISION BETA
MEANING
Locks the system
Unlocks the system
Removes the system lock
Selects the sectors to be updated
Selects the blocks within sectors to be updated
Blocks sending of PFAL commands through the
selected communication mode
Resets the system
Resets the system into the update mode.
Shuts down the system
Resets the user configuration to default settings.
Sets the system into the sleep mode until one of the
set signals detected
Clears the user alarm settings and restarts the
system
Clears the user configuration settings and restarts
the system
Enters the system into a special configuration
update mode to change the alarm configurations.
Configures a system timer
Starts/restarts a system timer
Stops a running timer
Pauses (suspends) a running timer
Restarts the execution of a paused timer
V 1.0.0
ERSION
Chapter
3.2.1.1.1
3.2.1.1.2
3.2.1.1.3
3.2.1.2.1
3.2.1.2.2
3.2.1.2.3
3.2.1.3.1
3.2.1.3.2
3.2.1.3.3
3.2.1.3.4
3.2.1.3.5
3.2.1.3.6
3.2.1.3.7
3.2.1.3.8
3.2.1.4.1
3.2.1.4.2
3.2.1.4.3
3.2.1.4.4
3.2.1.4.5
