Sys.gsm (Gsm States And Events); Sys.power (Power States And Events) - FALCOM MAMBOII User Manual

C C
ONFIGURATION OMMAND
3.2.25.1.1.2.9
STATES-are checked every second
State notification code
Sys.GSM.sEnable
Sys.GSM.sDisable
EVENTS-are evaluated just when the event occurs
Event notification code
Sys.GSM.eEnable
Sys.GSM.eDisable

3.2.25.1.1.2.10 Sys.Power (POWER states and events)

STATES-are checked every second
State notification code
Sys.Power.sVoltage
EVENTS-are evaluated just when the event occurs
Event notification code
Sys.Power.eDetected
Sys.Power.eDropped
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

Sys.GSM (GSM states and events)

Meaning
True when the GSM engine of the MAMBOII device is powered up, until the GSM
engine results disabled.
True when the GSM engine of the MAMBOII device is turned off, until the GSM engine
results enabled.
Meaning
Occurs when the GSM engine of the device is enabled (powered up).
Occurs when the GSM engine of the device is disabled (powered off).
Table 19: GSM states and events.
Meaning
True when external power is applied to the device, until disconnected (voltage is greater
than or equal to 4.2 Volt).
Description
Occurs when external power is applied to the device and input voltage is greater than or
equal to 4.2 Volt.
Occurs when external power is removed/disconnected from the device or input voltage
falls below 4.2 Volt.
Table 20: System power states and events.
