3.2.7 "MSG" command type

3.2.7.1
Depending on the communication channel when a command is transmitted to the
MAMBOII, the command responses can be forwarded to another channel such as
Bluetooth, CSD or TCP.
checks the configuration settings of that channel - see chapter 3.2.10.4,
3.2.10.6.
For example,
Please, be sure that the connection to which the results of the sent command have to
be outputted/redirected is already established before executing a command. The
command will attempt to send its results until the connection to that channel is
established (for example, CSD).
If these commands will automatically be executed from the system, within
alarm(AL), then the results are outputted directly to the assigned channel (serial, CSD or
TCP) without considering the mode on this
3.2.7.1.1
Command syntax
Examples
Responses
Command description
Command responses are redirected to the serial interface (Bluetooth), unimportant
from which channel the command was received. The output text on the serial
interface can be evaluated and used to control other Bluetooth devices
connected to MAMBOII. This command can be sent through Bluetooth, CSD or TCP
communication channel, but results are redirected to the serial line. The format the
device uses
DEVICE.PFAL.SEND.FORMAT
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

"Send" command index

Before the MAMBOII device processes a command, first it
if the MAMBOII
$PFAL,MSG.Send.Serial,8,"MAMBOII outputs its GPS positions" from
a TCP channel, first it checks the mode specified with the
"MSG.Mode.TCP" command to define how to handle this message.
The settings are listed below:
- if the mode of "MSG.Mode.TCP" is defined to Command mode,
then the MAMBOII handles that message as a PFAL command
and the command responses are forwarded to the serial
interface.
- if the mode of "MSG.Mode.TCP" is defined to Data mode, then
the MAMBOII forwards that command/text directly to the serial
interface without processing it.
MSG.Send.Serial,<protocols>,<"text"> - Redirects command responses
to the serial interface (Bluetooth)
$PFAL,MSG.Send.Serial, <protocols>,<"text">
$PFAL,MSG.Send.Serial
$PFAL,MSG.Send.Serial,8,"MAMBOII outputs its GSP positions"
$PFAL,MSG.Send.Serial,0,"on
E.g. MAMBOII outputs its GSP positions*60
$GPRMC,012443.000,V,0000.0000,N,00000.0000,E,,,060180,,*1B
$<end>
$<MSG.Send.Serial>
$enqueued 107 Bytes to serial buffer
$SUCCESS
to send out
configuration-dependent.
2.4.0_ -
EVISION BETA
receives
channel.
,<protocols>,<"text &(entry)">
&(Date) at &(Time) it is moving at
the protocols
V
ERSION
3.2.10.5
the command
&(Speed) m/s"
and entered text
Page 120 of 271
