Run The Test - FALCOM MAMBOII User Manual

C C
ONFIGURATION OMMAND
address is available on the sticker inside the Keyfob battery tray-
Enter all 16- digits of this address.
Set configuration
c) Copy the configuration above, past them on the Editor
sending configuration
Editor
➒
d) Power up the Keyfob device.
Keyfob. Keyfob will be powered automatically when you insert the batteries.
e) The following table lists and describes the default functions indicated by the
middle LED on the Keyfob remote control.
LED
Color
Red
Red
Red
Red
Green
All LEDs can be controlled by the MAMBOII
Buttons
Pressing simultaneously all 3 buttons resets all functions on the Keyfob
10. Later on, copy all 4 alarms (AL1 to AL4) given above, past them on the Editor
them to MAMBOII either by clicking on "Start sending configuration"
with left mouse each configuration line individually.

4.3.2 Run the test

1. To test your loaded alarms (refer to the Figure 10 below), just perform a short-press on the
MAMBOII's left button (BTN0), after you release it, a beep tone on the MAMBOII unit will
be heard for ON = 500 msec and OFF = 1000 msec.
2. To turn off this beep tone perform a long-press on the MAMBOII's left button (BTN0).
3. If the first test has been done successfully, take your Keyfob that is already connected to
the MAMBOII device and perform a short-press on the Button 1 (BTN1), the LED 1 on the
Keyfob will go flashing as follow ON = 1000 msec and OFF = 500 msec.
4. To turn off this LED indicator (LED0) perform a long-press on the on the Button 1 (BTN1).
5. To delete both alarms (AL1 and AL2), just transmit both alarms without settings to the
MAMBOII device as follow:
$PFAL,Cnf.Set,AL1
$PFAL,Cnf.Set,AL2
Other events, such as the GPS's Nav.eFix=[valid,invalid] are not triggered by the user,
but by your MAMBOII system when it gets or loses a GPS-fix. Whenever MAMBOII device
gets a valid GPS-fix, it generates the event "GPS.Nav.eFix=valid", while when it loses a
valid GPS fix it generates "GPS.Nav.eFix=valid". In the following example, when the GPS
data goes valid, an SMS message including the current location of the device will be
sent to the destination number (replace the existing phone number with your one ).
Before testing the following configuration, ensure that the device is already registered
