FALCOM MAMBOII User Manual page 21

C C
ONFIGURATION OMMAND
length of <cmd> commands is limited to 1500 characters. The common
syntax in this case is:
<cmd_1>;<cmd_2>;<cmd_3>....<cmd_n>
<parameter>
by the MAMBOII firmware. In some PFAL commands the <parameter> entry is
omitted. However, the specified parameter depends on the defined <cmd>
command. Some parameters do not require any value, so it will be left
empty. According to this explanation, the improved syntax to specify the
<parameter> is:
<parameter>=<value>
[<*CKSUM>]*
character (without double quotes) followed by two hex values. In order to
calculate the Checksum, use your own application. Below a small source
code written in Visual Basic:
//*****************************************
Public Sub CheckSum(field As String)
END SUB
//*****************************************
Therefore, the string over which the checksum has to be calculated is:
field = PFAL,<cmd>,<parameter>
excluding
be declared as a global variable.
Carriage Return plus Line Feed (ASCII CODE #13#10 (without any spaces) -
[<CRLF>]* *
hexadecimal: 0x0D 0x0A)
According to the explanations above, the improved syntax to specify a PFAL command is:
$PFAL,<c_type>.<c_index>.<c_subindex>,<parameter>=<value><*CKSUM><CR><LF>
$PFAL,<c_type>.<c_index>.<c_subindex>,<parameter>=<value><CR><LF>
PFAL,<c_type>.<c_index>.<c_subindex>,<parameter>=<value><*CKSUM><CR><LF>
PFAL,<c_type>.<c_index>.<c_subindex>,<parameter>=<value><CR><LF>
For example:
1) $PFAL,SYS.Device.Reset*31<CR><LF>
2) $PFAL,Sys.Trigger5<CR><LF>
3) $PFAL,IO.Beep3=hpulse,1000 <CR><LF>
4) $PFAL,IO.Vibration=hpulse,5000;MSG.Send.Serial,0,"Phone is vibrating"<CR><LF>
5) $PFAL,Sys.Timer0.Start=single,5000<CR><LF>
6) $PFAL,Cnf.Set,DEVICE.NAME="myMAMBOII"<CR><LF>
7) $PFAL,Cnf.Set,AL0=IO.BTN.e0=short:IO.Beep3=hpulse,1000<CR><LF>
*
Optional
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
The <parameter> can contain different valid parameters supported
If the checksum
If field = "" then CS = "*"
CS = 0
For i = 1 to Len(field)
CS = CS Xor Asc(Mid$(field, i, 1))
Next
CS = Hex(CS)
If Len(CS) =1 then CS = "0" & CS
CS = "*" & CS
The "CS" variable in the CheckSum procedure must
"$"character.
or
or
or
2.4.0_ -
EVISION BETA
is used, it consists of an asterisk "*"
<*CKSUM>
V 1.0.0
ERSION
Page 21 of 271
