Gps.area (Area States And Events) - FALCOM MAMBOII User Manual

C C
ONFIGURATION OMMAND
3.2.25.1.1.5.5
STATES-are checked every second
State notification code
GPS.Area.s<id>=<state_type>
<id>
<state_type>
EVENTS-are evaluated just when the event occurs
Event notification code
GPS.Area.e<id>=<event_type>
<id>
<event_type>
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

GPS.Area (Area states and events)

Meaning
True when the device enters into or leaves the area <id>.
Example: GPS.Area.s1=inside
GPS.Area.s1=outside
Used to identify the configured areas and to split states from different Areas.
Following are listed all supported area IDs.
0
1..31
Please, specifiy an area <id> that is already configured. How to configure an area
<id> refer to chapter .
It is optional. Defines the type of an area state, when it should be true.
inside - True as long as the device remains within the area <id>.
Once it results outside the area <id> goes false, and the
"GPS.Area.s<id>=outside" goes true.
outside - True as long as the device remains outside the area <id>.
Meaning
Occurs when the device enters into and/or leaves an Area <id>
Example: GPS.Area.e1=inside
GPS.Area.e1=outside
GPS.Area.eX=inside
GPS.Area.eX
Used to identify the configured areas and to split events from different Areas.
Following are listed all supported area IDs.
0
1..31
Please, specify an area <id> that is already configured, otherwise no event occurs.
How to configure an area <id> refer to chapter .
It is optional. Defines the type of an area event.
inside
outside - Occurs only when the device leaves the Area <id>
Table 32: Area states and events.
2.4.0_ -
EVISION BETA
- checks the state of parking area
- checks the state of a specific user-configured area
- used for parking area
- used for user-configured areas.
- Occurs only when the device enters into the Area <id>
V 1.0.0
ERSION
state
Page 225 of 271
