6.6 How to convert the coordinates

In order to convert coordinates from degrees, minutes, seconds format to decimal
format, use this easy formula:
degrees + (minutes/60) + (seconds/3600)
Min. coordinates would be calculated as:
For example:
•
Longitude (min) = 10°53'11" E
•
Latitude (min) = 50°40'16" N
Longitude (min)
X° Y' Z'' = [10 + (53/60) + (11/3600)] =
X° No conversion required
Latitude (min)
X° Y' Z'' = [50 + (40/60) + (16/3600)] =
X° No conversion required
Max. coordinates would be calculated as:
For example:
•
Longitude (max) = 10°57'17" E
• Latitude (max) = 50°42'41" N
Longitude (max)
X° Y' Z'' = [10 + (57/60) + (17/3600)] = 10.9547 //
X° No conversion required
Latitude (max)
X° Y' Z'' = [50 + (42/60) + (41/3600)] =
X° No conversion required

6.7 Explanation of the History Binary Data

Stored GPS history data into the history space memory can be retrieved either locally
(via serial link) or remotely (via a data or TCP connection). Whereby an executable
command, see chapters
such connection are available. Once, the MAMBOII receives such a command, it starts
to transfer the history selected data to the receiving device.
The history data is subdivided in packets, which are constructed in a specific binary
format to make possible low-cost solutions where data is downloaded via a TCP or GSM
connection.
For more detailed information about the history data conversion, see the Application
Note "AppNotes_Transform_history_data.pdf".
6.7.1 Maximum values & the time the history space will be used up
Entries
maximum distance
maximum speed
Satellites in view
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
3.2.4.2.5, page
Standing/slow
Value Unit
14 m
25.2 km/h
<15 -
2.4.0_ -
EVISION BETA
10.8863// Longitude (min)
50.6711// Latitude
Longitude (max)
50.7113// Latitude (max)
92 has to be sent to the MAMBOII device if
City Motorway
Value Unit Value Unit
510 m 32766 m
111.6 km/h 457.2 km/h
<15 - <15 -
V
ERSION
(min)
Full
Value Unit
>32766 m
457.2 km/h
<15 -
