FALCOM MAMBOII User Manual page 124

C C
ONFIGURATION OMMAND
device uses
DEVICE.PFAL.SEND.FORMAT
Parameter Description
<protocols>
It specifies the kind of protocols to be transmitted to the TCP server. Supported
protocols are listed in chapter
<"text">
It specifies the text to be added to the selected protocols and transmitted to the
TCP server. The text is limited to
quotation marks (" ") even if there is no text specified. The text is automatically
terminated by <CR><LF>.
If you want to output also any system state (dynamic entry) when the command
is executed, the syntax of the <"text"> can be changed to:
"text&(<entry
Each dynamic entry is separated by ampersand "&" without spaces and it is
enclosed in parentheses "( )".
The command to execute such notification might look like this:
For example:
$PFAL,MSG.Send.TCP,0,"on
Dynamic entries are listed in chapter
Notes
• In order to receive more than one protocol at once, you have to specify the
<protocols> in the hexadecimal value and add the corresponding hex value
of required protocols, for example:
− the
"$PFAL,MSG.Send.TCP,27,"test"" means the GGA+GSA+GSV+VTG
protocols will be received at once,
−
the
"$PFAL,MSG.Send.TCP,4E,"test"
GGA+GSA+GSV+RMC+IOP protocols will be received at once.
•
The defined user protocols (in hexadecimal value) will be transmitted only
one time after request and not periodically.
• The user text is sent first, followed by the protocols.
•
Set <protocols> to 0 to transmit only the specified text.
• If the TCP connection is currently not established, this data will be written into
the TCP buffer, which will be sent out as soon as the TCP connection will be
re-established.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
to send out
configuration-dependent.
>)text&(<entry >)text...&(<entry
1 2
&(Date)
hex value
hex value
2.4.0_ -
EVISION BETA
the protocols
6.3 page 245.
characters and it must be wrapped in
200
>)"
n
at &(Time) it is moving at
6.2 page 243.
27 added
4E added
V
ERSION
and entered text
&(Speed) m/s"
on the message
on the message
" means
Page 124 of 271
1.0.0
is
the
