FALCOM MAMBOII User Manual page 27

C C
ONFIGURATION OMMAND
PFAL COMMAND SET
$PFAL,Sys.CPU.Reset
$PFAL,Sys.IEEE.Enable
$PFAL,Sys.IEEE.Disable
$PFAL,Sys.IEEE.Reset
DISPLAY commands
$PFAL,Display.Show=<view>
$PFAL,Display.Dialog=<id>,<"caption">,<icon>,<tim
eout>,<"left-option">,<"right-option">,<"text">
$PFAL,Display.Alarm=<image>,<timeout>,<"text">
CNF Configuration commands
$PFAL,Cnf.Set,<parameter_name=value>
$PFAL,Cnf.Get,<parameter_name>
$PFAL,Cnf.Clear,<parameter_name>
$PFAL,Cnf.ShowUser
$PFAL,Cnf.ShowDefault
$PFAL,Cnf.Show
$PFAL,Cnf.Search,<parameter_name>
IO commands
$PFAL,IO.Beep<index>=<config_type>
$PFAL,IO.Vibration=<config_type>
GPS commands
$PFAL,GPS.Nav.Position<buffer_index>
$PFAL,GPS.Nav.Position<buffer_index>=<type>
$PFAL,GPS.Nav.Position<buffer_index>=save<storage_in
dex>
$PFAL,GPS.Nav.Position<buffer_index>=load<storage_ind
ex>
$PFAL,GPS.Nav.Distance
$PFAL,GPS.Nav.Distance=<value>
$PFAL,GPS.Nav.SaveLastValid
$PFAL,GPS.Nav.PowerSave=<on>,<onTime>,<lpTime>
$PFAL,GPS.History.Write,<add_prot_to_memory>,<"text">
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
2.4.0_ -
EVISION BETA
MEANING
Resets main controller and set system into the
firmware update mode.
Powers on IEEE module
Powers off IEEE module
Resets IEEE module.
Shows a specific view on the screen.
Creates and displays a dialog box on the screen.
Displays a specific alarm icon on the screen
Sets up or changes device configuration settings
Retrieves configuration
parameter name
Clears the configuration settings of the set
parameter name
Retrieves user settings
Retrieves default settings
Retrieves settings of all used parameters
Searches for a parameter name (text type)
Generates beep tones
Manages device vibrations
Retrieves the distance of the device from a stored
location
Saves temporarily a device location
Moves the GPS data from the buffer and stores it to
a storage index
Loads the GPS data from storage to buffer index for
temporarily use
Retrieves the distance from a start point
Sets/resets the distance to a user defined value
Saves last valid position.
Enables/Disables the low power mode of GPS
receiver.
Records a GPS position data into the history
memory
V
ERSION
Chapter
3.2.1.13.1
3.2.1.14.1
3.2.1.14.2
3.2.1.14.3
3.2.1.15.1
3.2.1.15.2
3.2.1.15.3
3.2.2.1
settings of the set
3.2.2.2
3.2.2.3
3.2.2.4
3.2.2.5
3.2.2.6
3.2.2.7
3.2.3.1.1
3.2.3.2.1
3.2.4.1.1
3.2.4.1.2
3.2.4.1.3
3.2.4.1.4
3.2.4.1.5
3.2.4.1.6
3.2.4.1.7
3.2.4.1.8
3.2.4.2.1
Page 27 of 271
1.0.0
