6.5.1.7
The $GPIOP message includes the status of the digital/analogue inputs and output
ports of the device (only for STEPPII, STEPPIII and BOLERO).
Example:
$GPIOP,00001000,00000010,0.00,0.28,0.00,0.28,11,90,4.15*72
Field Format
1 $GPIOP
2 bbbbbbbb
3 bbbbbbbb
4 x.xx
5 x.xx
6 x.xx
7 x.xx
8 x.xx
9 x.xx
10 *hh
11 <CR><LF>
6.5.1.8
The $GPGSM message includes the GSM operator and reception status. In the $GPGSM
message the number of the caller will also be transmitted if the caller number is not
available in the access/authorization list. Table below shows the mode, which indicates
that the sentence gives the GSM module status.
Example:
$GPGSM,0,1,0,"T-Mobile
Field Format
1 $GPGSM
2 x
3 b
4 x
5 "a"
6 xx
7 a
8 a
9 *hh
10 <CR><LF>
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

$GPIOP message

Example Description
$GPIOP Start of sentence
00000100 Inputs (I/O3-I/O0): 8-4 (unused); (1: high, 0: low)
00000001 Outputs (I/O1-I/O0): 8-2 (unused); (1: on, 0: off)
0.00 Analog input 0 (V) - I/O0.
0.28 Analog input 1 (V) - I/O1.
0.00 Analog input 2 (V) - I/O2.
0.28 Analog input 3 (V) - I/O3.
11.90 Main power voltage (V)
4.15 Backup battery voltage (V)
*72 Checksum
End of message termination
Table 56: The GPIOP message data format

$GPGSM message

D",20,5518,4caa*32
Example
$GPGSM
0
1
0
"T-Mobile D"
20
5518
4caa
*32
Table 58: The GPGSM message data format in GMS status mode.
2.4.0_ -
EVISION BETA
Description
Start of sentence
GSM status mode: 0
Registration (1:registered, 0: unregistered;5: roaming)
GSM status
Network operator name
GSM field strength (0 to 31) 0: $-$113 dB 31: $-$51 dB
Area code
Cell ID
Checksum
End of message termination
