- Page 1 HIS DOCUMENT IS AVAILABLE AT HTTP FALCOM DISCO-B5-MAGNET Hardware manual Version: 1.0.1; Modified: Thursday 4 October 2012...
-
Page 2: Table Of Contents
6.1.2.3 How to use these pins as digital outputs (I/O2 and I/O3)............23 6.1.3 Serial communication signals (RxA and TxA)............24 6.2 How to configure Track and Anti-tamper detection...........24 This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 2 of 35... - Page 3 - Added "Hint:" - An annual replacement of the O'ring rubber recommended. - Added chapter 7.1.1 Procedure for greasing the O-ring. 1.0.0 F. Beqiri - Initial version. 19/10/2011 This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 3 of 35...
- Page 4 No patent liability is assumed with respect to the use of the information contained herein. Note Specifications and information given in this document are subject to change by FALCOM without notice. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 4 of 35...
-
Page 5: Introduction
Security / emergency services, • Personalized drivers logbook, • Route verification / Trip management / Distance calculations, • Theft protection, This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 5 of 35... -
Page 6: Circuit Concept
Inside SIM card holder for 1,8/3 V SIM cards 8pin connector Figure 1: DISCO-B5-MAGNET block diagram This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 6 of 35... -
Page 7: Related Documents
These PDF files are viewable and printable from Adobe Reader. If you do not have the Adobe Reader installed, you can download it from http://www.adobe.com. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 7 of 35... -
Page 8: Security
When applications are prepared for mobile use, they should fulfil road- safety instructions of the current law! This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 8 of 35... -
Page 9: Electronic Devices
Do not transport or store flammable gas, liquid or explosives, in the compartment of your vehicle, which contains your modem or accessories. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 9 of 35... - Page 10 This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 10 of 35...
-
Page 11: Safety Standards
European Community, Directorate General V in matters of radio frequency electromagnetic energy. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 11 of 35... -
Page 12: Technical Data
➢ Accessible via PFAL commands. ➢ Upgradable locally via serial port and remotely over the air (GPRS/TCP). ➢ This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 12 of 35... -
Page 13: Power Consumption
Max. Unit Storage temperature °C Operating temperature °C Charging temperature °C Discharging temperature °C Table 2: Operating temperature This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 13 of 35... -
Page 14: Gsm/Gprs Engine Features
Please note that, the values listed above are the maximum ratings which, in practice, are influenced by a great variety of factors, primarily, for example, traffic variations and network coverage. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 14 of 35... -
Page 15: Gps Engine Features
AssistNow Offline, ➢ Crystal oscillator (TCXO): Load sensitivity ± 10 % load change, 0.2 ± ppm ➢ This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 15 of 35... -
Page 16: Nmea Data Message
User protocol including time, date, position, course and speed data in binary format (small sized - only 21 characters) Table 4: NMEA Output Messages This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 16 of 35... -
Page 17: Disco-B5-Magnet
5.1.2 Automatic shutdown Automatic shutdown takes effect if: • Battery voltage level runs low and external power supply is disconnected. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 17 of 35... -
Page 18: Power Saving
(DTE) using the following signals: DISCO-B5-MAGNET Terminal (DCE) Application (DTE) <---------- ----------> Table 5: The signalling definitions between DTE and DCE. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 18 of 35... -
Page 19: Hardware Interfaces
This figure shows the main parts of the DISCO-B5-MAGNET. 6/8pin female socket, pin assignments Figure 3: Pin assignments of the 6/8pin female socket. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 19 of 35... -
Page 20: Pinout Of The 6/8Pin Female Socket
Low and High events. PFAL,IO6.Set=high[low,hpulse,lpulse,cyclic] //6 = I/O3; high = sets output to high. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 20 of 35... -
Page 21: How To Use Them As Analog Inputs
0 to 2.5 V. An application example is shown in figure below: Figure 4: Connection example 1 when used as analog input. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 21 of 35... -
Page 22: How To Use These Pins As Digital Inputs (I/O2 And I/O3)
Connection example when using it as digital input A completed circuit example for all inputs is attached in section 9.1.1. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 22 of 35... -
Page 23: How To Use These Pins As Digital Outputs (I/O2 And I/O3)
Connection example 1 when using it to control an Relay. Figure 8: Connection example 2 when using it to control an LED This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 23 of 35... -
Page 24: Serial Communication Signals (Rxa And Txa)
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 24 of 35... -
Page 25: Manual Version
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 25 of 35... -
Page 26: Opening The Unit And Inserting The Sim Card In The Sim Card Holder
Note: During removing the screws, don't lose the spacer rings between the metal plate and the device (marked on the figure on right side). Figure 11: Removing screws, nuts and spacer rings This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 26 of 35... -
Page 27: This Confidential Document Is A Property Of Falcom And May Not Be Copied Or Circulated Without Previous Permission
Place the cover back on to the lower case so that the holes at the outer edges of both cases fit exactly to each other. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 27 of 35... -
Page 28: This Confidential Document Is A Property Of Falcom And May Not Be Copied Or Circulated Without Previous Permission
Figure 14: Mounting back the metal plate on the device This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 28 of 35... -
Page 29: Procedure For Greasing The O-Ring
Farnell website: http://cpc.farnell.com/1/1/42871-silicone-compond-dc4-2793695-dow-corning.html Picture 16: Needed Remove the old O-ring using standard tweezers (not included) as shown below. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 29 of 35... -
Page 30: Enter The Pin Of The Sim Card
Parity bit, 1 Stop bit, None Flow control). Next, click on the Connect icon on the left of the text "Port", to connect to. Connect the Console to the COM Port and the Editor This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 30 of 35... -
Page 31: This Confidential Document Is A Property Of Falcom And May Not Be Copied Or Circulated Without Previous Permission
Figure 17: Starting the Workbench software and enter the PIN code of the inserted SIM card. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 31 of 35... -
Page 32: Magnetic Mount Installation
To dismount the magnetically mounted device take the device on the wings using your hands and lift. Figure 18: Mount and dismount the device. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 32 of 35... -
Page 33: Housing
DISCO-B5-MAGNET H 1.0.1 ARDWARE ANUAL ERSION 8 HOUSING Figure 19: DISCO-B5-MAGNET housing. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 33 of 35... -
Page 34: Appendix
MAGNET. With the vehicle ignition off attach the power pins to DISCO-B5-MAGNET (FIRST connect the GND pin and then the +IN pin). Figure 20: Schematic example of installation guidance. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 34 of 35... -
Page 35: What Should Be Considered When Using The Disco-B5-Magnet Device
Workbench software which is free of charge and can be downloaded from the FALCOM's website (http://www.falcom.de). A description of PFAL commands is available in the software manual “AVL_PFAL_Configuration_Command_Set.pdf”. This confidential document is a property of FALCOM and may not be copied or circulated without previous permission. Page 35 of 35...
