<size>
Specifies the exact length of the remote update firmware data. For FW_raw, this
number specifies the length (in bytes) of the binary firmware data. For FW_cpr,
this number specifies the length (in bytes) of the compressed firmware data.
<sectors>
Specifies how large the new firmware is (how many sectors it uses in
uncompressed format) – one sector is 64 KB. Example: a firmware uses 14 sectors,
so 14 has to be specified for <size>.
<config>
Value
raw_cfg
compressed_cfg
current_cfg
3.2.1.2.2
Command
Sys.RUpdate.DataMode,<msg_input>
syntax
Examples $PFAL,Sys.RUpdate.DataMode,TCP
Message description
Enters the data mode, which allows only entering of binary update commands.
Inside this mode, no PFAL commands can be executed.
Parameter description
<msg_input>
Specifies in which channel the firmware-based packets will be received. Now
binary Update commands can be sent (see next chapter).
Value
Serial
TCP
CSD
Note:
•
This command can be executed anytime after a remote update has been
initiated (Rupdate.Init)
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
Meaning
Erases the device configuration during the update
process. A new (uncompressed) configuration can be
transmitted via remote update. (see select sector for
more details). Config can still be used until the remote
update is finished ; after finishing, the old configuration will
be cleared
A new configuration is stored within the compressed
firmware. No separate config will be needed. It is not
allowed to write uncompressed configuration data to the
configuration sector if compressed_cfg is selected.
Uses the currently stored device configuration later. No
separate configuration needs to be specified. An existing
compressed configuration would be overwritten.
Sys.RUpdate.DataMode,<msg_input> – Defines transfer channel &
continues upgrading
Meaning
Received via serial line
Received via a TCP connection (from MAMBOII server)
Received via a CSD call (GSM datacall)
