3.2.1.15 "DISPLAY" command type

3.2.1.15.1 Display.Show – Displays a specific view on the MAMBOII's screen
Command syntax $PFAL,Display.Show=<view>
$PFAL,Display.Show=VIEW_GSM
$PFAL,Display.Show=VIEW_GPS
Examples
......
......
Responses E.g $SUCCESS
Command description
This command displays a specific view on the MAMBOII's screen.
Parameter description
<view>
Determines the view to be displayed on the screen. Following views are
supported:
Value
VIEW_GSM
VIEW_GPS
VIEW_SKY
VIEW_SAT
VIEW_MENU
VIEW_PBOOK
VIEW_TACHO
VIEW_KOMPASS
VIEW_HEADING
VIEW_MILOMETER
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
Meaning
Displays the GSM view (graphically displays the GSM
operator name and field strength - A line made up of a series of
dashes)
Displays the GPS view (graphically displays the current
Location, Speed and Direction)
Displays the SKY view (graphically displays the number and
position of the satellites on the horizon in the form of a polar
plot)
Displays the SAT view (graphically and textually displays the
satellite number, status, azimuth, elevation, C/No, and last five
seconds of measured signal strength)
Displays the first Menu view (displays the main menu
created with DISP.MENU<id>)
Displays the PBook view (displays all phonebook entries
created with DISP.PHONE<index>)
Displays the Tacho view (graphically and textually displays
the current speed in km/h)
Displays the Compass view (graphically displays the
current direction you are going)
Displays the Heading view (graphically displays the current
direction you are going and current speed you are moving)
Displays the Milemeter view (graphically displays in
miles the current distance travelled from a start point)
