3.2.11 DISP Parameter

Parameter DISP enables you to personalize the device to suit the end users needs. The
display is designed for one-handed navigation using the five-way key and two other
keys rather than a touch screen display.
3.2.11.1 DISP.VIEW<index>
Parameter syntax
This parameter allows you to determine the background view used for home
screen and the views displayed when navigating with 5-way key.
<index>
Defines when a specific view should be displayed on the screen. It can be set as
follow:
Value
0
1 ... 4
<show_view>
Specifies the background view to be displayed. Following views are currently
available.
Value
VIEW_GSM
VIEW_GPS
VIEW_SKY
VIEW_SAT
VIEW_MENU
VIEW_PBOOK
VIEW_INFO
How to set/get display configuration:
$PFAL,Cnf.Set,DISP.VIEW1=
Set configuration
$PFAL,Cnf.Get,DISP.VIEW1
Get configuration
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
DISP.VIEW<index>=<show_view>
Meaning
The background view used for the home screen.
The view to be displayed when navigating with the 5-way
key. (1 = up, 3 = right, 2 = down and 4 = left)
Meaning
Displays the GSM view (graphically shows the current
operator name and the field strength etc.)
Displays the GPS view (graphically shows the current Location,
Speed and Direction)
Displays the SKY view (graphically shows the number and
position of the satellites on the horizon in the form of a polar
plot)
Displays the SAT view (graphically and textually shows the
satellite number, status, azimuth, elevation, C/No, and last five
seconds of measured signal strength).
Displays the first Menu view (shows the main menu
created with DISP.MENU<id>).
Displays the PBook view (shows all phonebook entries created
with DISP.PHONE<index>).
Displays the info view.
