3.2.12 IEEE Parameter

3.2.12.1 IEEE.PANID

Parameter syntax
This parameter allows you to specify the PAN (Personal Area Network) identifier. See
chapter
4.3
<id>
Specifies the network identifier in hexadecimal value.
Any valid network identifier in range of 0000 ... FFFF.
How to set/get IO configuration:
$PFAL,Cnf.Set,IEEE.PANID=CAF0
Set configuration
$PFAL,Cnf.Get,IEEE.PANID
Get configuration
Notes
•
If there are the same IDs in a nearby Network, then the MAMBOII will
automatically generate a new ID.
•
Disable
PFAL,Sys.IEEE.[Disable,Enable]
configuration completes.
3.2.12.2 IEEE.KEYFOB<cnf_kf_div_index>
Parameter syntax
This parameter allows you to make a connection to a Keyfob. To enable
communication between MAMBOII and Keyfob device, the MAMBOII must know
the address of all Kefob devices to allow a connection request. MAMBOII device is
configured to start the IEEE 802.15.4 network and will serve as the PAN coordinator
in that network. See chapter
<cnf_kf_div_ndex>
It specifies the index from 0 to 5 of the Keyfob being connected. The index
differentiates similar Keyfob devices from each other. Up to 6 IEEE enabled
devices (Keyfobs + I/O-BOXes) are supported by the MAMBOII. Depending on
your requirements you may connect
I/O-BOXes, refer to the parameter "IEEE.IOBOX<index>".
<sec_mode>
Because many devices might connect over a wireless IEEE connection and get
the data that is transmitted from, this setting specifies the type of connection
security. It can be set to:
Value
0
1
<address>
Defines the address that identifies your Keyfob to register it to the BOERO-QUAD.
Enter all 16-digits derived from the MAC address of the Keyfob.
The MAC address is given on the sticker on the back inside the Keyfob (
tray and remove batteries
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
IEEE.PANID=<id>
as reference.
and enable
IEEE.KEYFOB<cnf_kf_div_ndex>=
as reference.
4.3
Meaning
Disables encrypted transmissions.
Enables encrypted transmissions (currently not implemented).
). Every Keyfob device has an unique MAC address.
2.4.0_ -
EVISION BETA
IEEE chip inside
accordingly)
<sec_mode>,<address>
2 Keyfobs and
V
ERSION
manually
after your IEEE-specified
I/O-BOXes. To configure
4
open the
Page 163 of 271
1.0.0
(using
