C C
ONFIGURATION OMMAND
Locate the zone you want to define on the map, and note down the min
longitude/Latitude and the max longitude/Latitude coordinates of a rectangle that
defines the zone/GeoFence, as shown in figure below.
In our example (in degrees, minutes, seconds):
Longitude (min)
Latitude (min)
Longitude (max)
Latitude (max)
In order to convert coordinates from degrees, minutes, seconds format to decimal
format, refer to chapter
You have now determined the grid coordinates for your rectangular zone/GeoFence.
One last step before setting up the configuration, is to determine the sign of the
coordinate values. Please remember that, Latitude North and Longitude East are
positive and Latitude South and Longitude West are negative (see also figure below):

3.2.24.2 Set up the Geofencing zones and areas

Set up the configuration as normal based on the parameter syntax, and enter the
parameters as indicated in chapter
obtained from chapter 6.6, page
$PFAL,Cnf.Set,GF3= area<flag>,"name",R,<La_Min>,<Lo_Min>,<La_Max>,<Lo_Max>
$PFAL,Cnf.Set,GF3= area<flag>,"Ilmenau",R,50.6711,10.8863,50.7113,10.9547
An established GeoFence supports two different events:
1.
2.
An area supports also two different events:
1.
2.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
Figure 6: Determine the Zone's Grid Coordinates
= 10°53'11" E
= 50°40'16" N
= 10°57'17" E
= 50°42'41" N
6.6, "How to convert the
Figure 7: Determining the sign of the coordinate values
when the vehicle enters the pre-defined GeoFence boundaries.
when the vehicle leaves into the pre-defined GeoFence boundaries.
when the vehicle enters into the area boundaries *.
when the vehicle leaves the area boundaries *.
* geographic boundaries are set automatically from a collection of set Geofences
2.4.0_ -
EVISION BETA
coordinates", page 257.
3.2.24.5, "GF<id>", page 201. The set values are
257.
