Gsm (Gsm States And Events); Gsm (Gsm Operator States And Events); Gsm.ecellchange (Cell States And Events) - FALCOM MAMBOII User Manual

C C
ONFIGURATION OMMAND

3.2.25.1.1.6 GSM (GSM states and events)

3.2.25.1.1.6.1
STATES-are checked every second
State notification code
GSM.sOpValid=<"operator_name">
GSM.sOpInvalid=<"operator_name">
<"operator_name">
EVENTS-are evaluated just when the event occurs
Event notification code
GSM.eOpFound=<"operator_name">
GSM.eOpLost=<"operator_name">
<"operator_name">
3.2.25.1.1.6.2
STATES
None
EVENTS-are evaluated just when the event occurs
Event notification code Meaning
GSM.eCellChange
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE

GSM (GSM Operator states and events)

Meaning
True when a (specific) GSM network operator is available until the GSM network
operator results invalid. Once it results invalid, the "GPS.sOpInvalid.." state
responds true. State is checked every second.
Example:
True when a (specific) GSM network operator fails until the GSM network operator
results valid. Once it results valid the "GPS.sOpValid.." state responds true. State
is checked every second.
It is optional. It specifies in quotation marks (" ") the GSM operator name (i.e. "T-
Mobile D") to be compared. The comparison is case sensitive and must match
exactly the obtained operator name.
Meaning
Occurs when the device finds a (specific) GSM network operator and registered to
that GSM operator.
Example:
Occurs when the device loses a (specific) GSM network operator.
It is optional. It specifies in quotation marks (" ") the GSM operator name (i.e. "T-
Mobile D") to be compared. The comparison is case sensitive and must match
exactly the obtained operator name.
Table 33: GSM Operator states and events

GSM.eCellChange (Cell states and events)

Occurs when the device is already connected to the GSM network and it changes the GSM
network cell (hand-over).
Example: GSM.eCellChange
Table 34: GSM Cell states and events
2.4.0_ -
EVISION BETA
GSM.sOpValid="T-Mobile D"
GSM.eOpFound="T-Mobile D"
V 1.0.0
ERSION
Page 226 of 271
