Register Details: Digital I/O - Analog Devices ADuCM320 Hardware Reference Manual

ADuCM320 Hardware Reference Manual
Address Name
0x40020244 GP5OE
0x40020248 GP5PUL
0x4002024C GP5IE
0x40020250 GP5IN
0x40020254 GP5OUT
0x40020258 GP5SET
0x4002025C GP5CLR
0x40020260 GP5TGL
0x40020264 GP5ODE

REGISTER DETAILS: DIGITAL I/O

Note that not all bits are accessible to the user on some ports. Inaccessible bits are reserved and must be ignored. See Table 121 for more
details on the accessible bits.
GPIO Port Configuration Registers
Address: 0x40020000, Reset: See Table 122, Name: GP0CON
Address: 0x40020040, Reset: See Table 122, Name: GP1CON
Address: 0x40020080, Reset: See Table 122, Name: GP2CON
Address: 0x400200C0, Reset: See Table 122, Name: GP3CON
Address: 0x40020100, Reset: See Table 122, Name: GP4CON
Address: 0x40020240, Reset: See Table 122, Name: GP5CON
Table 123. Bit Descriptions for GP0CON, GP1CON, GP2CON, GP3CON, GP4CON, and GP5CON
Bits Bit Name
[15:14] CON7
[13:12] CON6
[11:10] CON5
[9:8] CON4
[7:6] CON3
[5:4] CON2
[3:2] CON1
[1:0] CON0
1 Where x is 0 for Port 0, 1 for Port 1, 2 for Port 2, and 3 for Port 3.
GPIO Port Output Enable Registers
Address: 0x40020004, Reset: 0x00, Name: GP0OE
Address: 0x40020044, Reset: 0x00, Name: GP1OE
Address: 0x40020084, Reset: 0x00, Name: GP2OE
Address: 0x400200C4, Reset: 0x00, Name: GP3OE
Address: 0x40020104, Reset: 0x00, Name: GP4OE
Address: 0x40020244, Reset: 0x00, Name: GP5OE
Table 124. Bit Descriptions for GP0OE, GP1OE, GP2OE, GP3OE, GP4OE, and GP5OE
Bits Bit Name
[7:0] OE
Description
GPIO Port 5 output enable
GPIO Port 5 pull-down enable
GPIO Port 5 input path enable
GPIO Port 5 registered data input
GPIO Port 5 data output
GPIO Port 5 data out set
GPIO Port 5 data out clear
GPIO Port 5 pin toggle
GPIO Port 5 open-drain enable
Description
Configuration bits for Port x.7. See Table 121.
Configuration bits for Port x.6. See Table 121.
Configuration bits for Port x.5. See Table 121.
Configuration bits for Port x.4. See Table 121.
Configuration bits for Port x.3. See Table 121.
Configuration bits for Port x.2. See Table 121.
Configuration bits for Port x.1. See Table 121.
Configuration bits for Port x.0. See Table 121.
Description
Pin output drive enable
0: disable the output on the corresponding GPIO
1: enable the output on the corresponding GPIO
Rev. C | Page 97 of 196
Reset
1 See Table 122
See Table 122
See Table 122
See Table 122
See Table 122
See Table 122
See Table 122
See Table 122
UG-498
Reset RW
0x00 RW
0x0 RW
0xF RW
0xXX R
0x0 RW
0x0 W
0x0 W
0x0 W
0x0 RW
Access
RW
RW
RW
RW
RW
RW
RW
RW
Reset Access
See Table 122 RW
