Analog Devices ADuCM320 Hardware Reference Manual page 70

UG-498
DMA Channel Enable Clear Register
Address: 0x4001002C, Reset: 0x00000000, Name: DMAENCLR
Table 86. Bit Descriptions for DMAENCLR
Bits Bit Name
[31:14] RESERVED
[13:0] CHENCLR
DMA Channel Primary-Alternate Set Register
Address: 0x40010030, Reset: 0x00000000, Name: DMAALTSET
The DMAALTSET register enables the user to configure the appropriate DMA channel to use the alternate control data structure.
Reading the register returns the status of which data structure is in use for the corresponding DMA channel. Each bit of the register
represents the corresponding channel number in the DMA controller.
Note that the DMA controller sets/clears these bits automatically as necessary for ping-pong, memory scatter-gather, and peripheral
scatter-gather transfers.
Table 87. Bit Descriptions for DMAALTSET
Bits Bit Name
[31:14] RESERVED
[13:0] CHPRIALTSET
DMA Channel Primary-Alternate Clear Register
Address: 0x40010034, Reset: 0x00000000, Name: DMAALTCLR
The DMAALTCLR write-only register enables the user to configure the appropriate DMA channel to use the primary control data
structure. Each bit of the register represents the corresponding channel number in the DMA controller.
Note that the DMA controller sets/clears these bits automatically as necessary for ping-pong, memory scatter-gather and peripheral
scatter-gather transfers.
Table 88. Bit Descriptions for DMAALTCLR
Bits Bit Name
[31:14] RESERVED
[13:0] CHPRIALTCLR
Description
Reserved. Undefined.
Disable DMA channels. This register allows for the disabling of DMA channels. Reading
the register returns the enable status of the channels. Each bit of the register represents
the corresponding channel number in the DMA controller. Note that the controller
disables a channel automatically, by setting the appropriate bit, when it completes the
DMA cycle.
Set the appropriate bit to disable the corresponding channel.
Bit 0 corresponds to DMA Channel 0, and Bit M-1 corresponds to DMA Channel M-1.
When written:
Bit [C] = 0, no effect. Use the DMAENSET register to enable the channel.
Bit [C] = 1, disables Channel C.
Description
Reserved. Undefined.
Control structure status/select alt struct. Returns the channel control data structure
status, or selects the alternate data structure for the corresponding DMA channel.
Bit 0 corresponds to DMA Channel 0, and Bit M-1 corresponds to DMA Channel M-1.
When read:
Bit [C] = 0, DMA Channel C is using the primary data structure.
Bit [C] = 1, DMA Channel C is using the alternate data structure.
When written:
Bit [C] = 0, no effect. Use the DMAALTCLR register to set Bit [C] to 0.
Bit [C] = 1, selects the alternate data structure for Channel C.
Description
Reserved. Undefined.
Select primary data struct. Set the appropriate bit to select the primary data
structure for the corresponding DMA channel.
Bit 0 corresponds to DMA Channel 0, and Bit M-1 corresponds to DMA Channel M-1.
When written:
Bit [C] = 0, no effect. Use the DMAALTSET register to select the alternate data structure.
Bit [C] = 1, selects the primary data structure for Channel C.
ADuCM320 Hardware Reference Manual
Rev. C | Page 70 of 196
Reset Access
0x0 R
0x0 W
Reset Access
0x0 R
0x0 RW
Reset Access
0x0 R
0x0 W
