Compare Register 1 for PWM4 and PWM5
Address: 0x40024034, Reset: 0x0000, Name: PWM2COM1
Table 281. Bit Descriptions for PWM2COM1
Bits Bit Name
[15:0] COM1
Compare Register 2 for PWM4 and PWM5
Address: 0x40024038, Reset: 0x0000, Name: PWM2COM2
Table 282. Bit Descriptions for PWM2COM2
Bits Bit Name
[15:0] COM2
Period Value Register for PWM4 and PWM5
Address: 0x4002403C, Reset: 0x0000, Name: PWM2LEN
Table 283. Bit Descriptions for PWM2LEN
Bits Bit Name
[15:0] LEN
Compare Register 0 for PWM6 and PWM7
Address: 0x40024040, Reset: 0x0000, Name: PWM3COM0
Table 284. Bit Descriptions for PWM3COM0
Bits Bit Name
[15:0] COM0
Compare Register 1 for PWM6 and PWM7
Address: 0x40024044, Reset: 0x0000, Name: PWM3COM1
Table 285. Bit Descriptions for PWM3COM1
Bits Bit Name
[15:0] COM1
Compare Register 2 for PWM6 and PWM7
Address: 0x40024048, Reset: 0x0000, Name: PWM3COM2
Table 286. Bit Descriptions for PWM3COM2
Bits Bit Name
[15:0] COM2
Period Value Register for PWM6 and PWM7
Address: 0x4002404C, Reset: 0x0000, Name: PWM3LEN
Table 287. Bit Descriptions for PWM3LEN
Bits Bit Name
[15:0] LEN
Description
Compare Register 1 data.
Description
Compare Register 2 data.
Description
Period value.
Description
Compare Register 0 data.
Description
Compare Register 1 data.
Description
Compare Register 2 data.
Description
Period value.
Rev. C | Page 183 of 196
UG-498
Reset Access
0x0 RW
Reset Access
0x0 RW
Reset Access
0x0 RW
Reset Access
0x0 RW
Reset Access
0x0 RW
Reset Access
0x0 RW
Reset Access
0x0 RW
