SERIAL PERIPHERAL INTERFACES

SPI FEATURES

Two complete hardware serial peripheral interfaces with the following standard SPI features:
•
Serial clock phase mode and serial clock polarity mode
•
LSB first transfer option
•
Loopback mode
•
Master or slave mode
•
Transfer and interrupt mode
•
Continuous transfer mode
•
Tx/Rx FIFO
•
Interrupt mode, interrupt after one, two, three, or four bytes
•
Rx overflow mode and Tx underrun mode
•
Open-circuit data output mode
•
Full duplex communications supported (simultaneous transmit/receive)

SPI OVERVIEW

The ADuCM320 integrates two complete hardware serial peripheral interfaces (SPI). SPI is an industry-standard, synchronous serial
interface that allows eight bits of data to be synchronously transmitted and simultaneously received, that is, full duplex. The two SPIs
implemented on the ADuCM320
The SPI blocks have an additional DMA feature. Each SPI block has two DMA channels that interface with a µDMA controller of the
ARM Cortex-M3 processor. One DMA channel is used for transmitting data and the other is used for receiving data.

SPI OPERATION

The SPI port can be configured for master or slave operation and consists of four pins: MISO, MOSI, SCLK, and CS .
Note that the GPIOs used for SPI communication must be configured in SPI mode before enabling the SPI peripheral and that the
internal pull-up resistors on the SPI pins should be disabled via the GPxPUL registers when using the SPI.
MISO (Master In, Slave Out) Pin
The MISO pin is configured as an input line in master mode and an output line in slave mode. The MISO line on the master (data in)
should be connected to the MISO line in the slave device (data out). The data is transferred as byte-wide (8-bit) serial data, MSB first.
MOSI (Master Out, Slave In) Pin
The MOSI pin is configured as an output line in master mode and an input line in slave mode. The MOSI line on the master (data out)
should be connected to the MOSI line in the slave device (data in). The data is transferred as byte-wide (8-bit) serial data, MSB first.
SCLK (Serial Clock I/O) Pin
The master serial clock (SCLK) synchronizes the data being transmitted and received through the MOSI SCLK period. Therefore, a byte
is transmitted/received after eight SCLK periods. The SCLK pin is configured as an output in master mode and as an input in slave mode.
In master mode, the polarity and phase of the clock are controlled by the SPIxCON register, and the bit rate is defined in the SPIxDIV
register as follows:
SPICLK
=
f
SERIALCLOC K
× +
2 1 ( SPIxDIV
where SPICLK is the 80 MHz system clock divided by the factor set in the CLKCON1[2:0] register.
It is possible to disable the clocks to SPI0 and SPI1 separately:
•
CLKCON5[0] = 1 disables the clock to SPI0.
•
CLKCON5[1] = 1 disables the clock to SPI1.
By reducing the clock rate to the SPI blocks, it is possible to reduce the power consumption of the SPI block.
The maximum data rate is 20 Mbps.
In slave mode, the SPIxCON register must be configured with the phase and polarity of the expected input clock. The slave accepts data
from an external master up to 20 Mbps.
can operate to a maximum bit rate of 20 Mbps in both master and slave modes.
)
