ADuCM320 Hardware Reference Manual

REGISTER SUMMARY: LOW VOLTAGE DIE INTERRUPTS

Table 61. Low Voltage Die Interrupts Register Summary
Address Name
0x40083004 INTCLR
0x40083008 INTSEL
0x4008300C INTSTA

REGISTER DETAILS: LOW VOLTAGE DIE INTERRUPTS

Interrupt Clear Register
Address: 0x40083004, Reset: 0x0000, Name: INTCLR
Table 62. Bit Descriptions for INTCLR
Bits Bit Name
7 CLR_WRECC_ERR
6 CLR_RDECC_ERR
5 CLR_IDAC_EXTRESLOW
4 CLR_IDAC_TSHUT
3 CLR_ACOMP
2 CLR_DCOMP
1 CLR_ADC_SEQ
0 CLR_ADC_SOFTCONV
Interrupt Mask Register
Address: 0x40083008, Reset: 0x0000, Name: INTSEL
Table 63. Bit Descriptions for INTSEL
Bits Bit Name
15 SEL_WRECC_ERR_0
14 SEL_RDECC_ERR_0
13 SLE_IDAC_EXTRESLOW_0
12 SEL_IDAC_TSHUT_0
11 SEL_ACOMP_0
10 SEL_DCOMP_0
9 SEL_ADC_SEQ_0
8 SEL_ADC_SOFTCONV_0
7 SEL_WRECC_ERR_1
6 SEL_RDECC_ERR_1
5 SLE_IDAC_EXTRESLOW_1
4 SEL_IDAC_TSHUT_1
3 SEL_ACOMP_1
2 SEL_DCOMP_1
1 SEL_ADC_SEQ_1
0 SEL_ADC_SOFTCONV_1
Description
Interrupt clear register
Interrupt mask register
Interrupt status register
Description
Write 1 to this bit to clear the write ECC error interrupt flag.
Write 1 to this bit to clear the read ECC error interrupt flag.
Write 1 to this bit to clear the IDAC EXTRESLOW interrupt flag.
Write 1 to this bit to clear the IDAC TSHUT interrupt flag.
Write 1 to this bit to clear the analog compare interrupt flag.
Write 1 to this bit to clear the digital compare interrupt flag.
Write 1 to this bit to clear the ADC sequence conversion interrupt flag.
Write 1 to this bit to clear the ADC software conversion interrupt flag.
Description
Write 1 to this bit to enable write ECC error interrupt for Interrupt Pin 0.
Write 1 to this bit to enable read ECC error interrupt for Interrupt Pin 0.
Write 1 to this bit to enable IDAC EXTRESLOW interrupt for Interrupt Pin 0.
Write 1 to this bit to enable IDAC TSHUT interrupt for Interrupt Pin 0.
Write 1 to this bit to enable analog comparator interrupt for Interrupt Pin 0.
Write 1 to this bit to enable digital comparator interrupt for Interrupt Pin 0.
Write 1 to this bit to enable ADC sequence conversion interrupt for
Interrupt Pin 0.
Write 1 to this bit to enable ADC software conversion interrupt for
Interrupt Pin 0.
Write 1 to this bit to enable write ECC error interrupt for Interrupt Pin 1.
Write 1 to this bit to enable read ECC error interrupt for Interrupt Pin 1.
Write 1 to this bit to enable IDAC EXTRESLOW interrupt for Interrupt Pin 1.
Write 1 to this bit to enable IDAC TSHUT interrupt for Interrupt Pin 1.
Write 1 to this bit to enable analog comparator interrupt for Interrupt Pin 1.
Write 1 to this bit to enable digital comparator interrupt for Interrupt Pin 1.
Write 1 to this bit to enable ADC sequence conversion interrupt for
Interrupt Pin 1.
Write 1 to this bit to enable ADC software conversion interrupt for
Interrupt Pin 1.
Rev. C | Page 57 of 196
UG-498
Reset RW
0x0000 W
0x0000 RW
0x0000 R
Reset Access
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
0x0 W
Reset Access
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
0x0 RW
