MB90335 Series
10.6

Program Examples of Watchdog Timer

Program example of watchdog timer is given below.
■ Program Examples of Watchdog Timer
●
Processing specification
• The watchdog timer is cleared each time in loop of the main program.
• The processing of the main loop must go round within the minimum interval time.
●
Coding example
WDTC
WTE
;----------Main program---------------------------------------------------
CODE
START:
;
WDG_START:
;----------Main loop-------------------------------------------------------
MAIN:
;
;
;
CODE
;----------Vector Settings---------------------------------------------------------
VECT
VECT
CM44-10137-6E
EQU 0000A8H
EQU WDTC:2
CSEG
:
MOV WDTC, #00000011B
CLRB I:WTE
:
User processing
:
JMP MAIN
ENDS
CSEG ABS=0FFH
ORG 0FFDCH
DSL START
DB 00H
ENDS
END START
FUJITSU MICROELECTRONICS LIMITED
CHAPTER 10 WATCHDOG TIMER
10.6 Program Examples of Watchdog Timer
; Watchdog timer control register
; Watchdog timer control bit
; Initialize such as a stack pointer (SP).
; Activating watchdog timer
21 ± 2 18
; 2 cycles in time of the interval are selected.
; Clearing watchdog timer
It is regularly clearness of two bits.
; Interval Time of Watchdog Timer
; Loop in the shortest possible time
; Reset vector setting
; Single-chip mode setting
