Physical Dimensions

Platform Depth
15-slot Chassis 15"
device
10-slot Chassis 15"
device
4-slot Chassis 15"
device
TurboIron/8 16.75"
FastIron
Workgroup
FastIron Backbone
NetIron stackable
ServerIron
ServerIronXL
ServerIronXL/G
TurboIron (4- to 6-
port Gigabit Layer
2 Switch)
D - 2
Table D.2: DC electrical specifications for Foundry devices
Input Voltage Range
-36VDC to -72VDC,
(-48VDC nominal)
-36VDC to -72VDC,
(-48VDC nominal)
Table D.3: Physical dimensions for Foundry devices
Width
17.5"
17.5"
17.5"
17.5"
Current Rating
Nominal Inrush
3 amps 3.7 amps
2 amps 3 amps
Length (Height)
29.75"
23"
9"
2.75"
Watts
150
100
Weight
256 lbs. fully
populated
69.1 lbs. fully
populated
47.7 lbs. fully
populated
18 – 22 lbs.
December 2000
