Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 Technical Manual page 519

Register name Address Bit
Areas 14–13 0048122 DF–9
set-up register (HW) D8
D7
D6
D5
D4
D3
D2
D1
D0
Areas 8–7 0048128 DF–9
set-up register (HW) D8
D7
D6
D5
D4
D3
D2
D1
D0
Areas 6–4 004812A DF–E
set-up register (HW) DD
DC
DB
DA
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
S1C33L03 FUNCTION PART
Name Function
– reserved
A14DRA Area 14 DRAM selection
A13DRA Area 13 DRAM selection
A14SZ Areas 14–13 device size selection
A14DF1 Areas 14–13
A14DF0 output disable delay time
– reserved
A14WT2 Areas 14–13 wait control
A14WT1
A14WT0
– reserved
A8DRA Area 8 DRAM selection
A7DRA Area 7 DRAM selection
A8SZ Areas 8–7 device size selection
A8DF1 Areas 8–7
A8DF0 output disable delay time
– reserved
A8WT2 Areas 8–7 wait control
A8WT1
A8WT0
– reserved
A6DF1 Area 6
A6DF0 output disable delay time
– reserved
A6WT2 Area 6 wait control
A6WT1
A6WT0
– reserved
A5SZ Areas 5–4 device size selection
A5DF1 Areas 5–4
A5DF0 output disable delay time
– reserved
A5WT2 Areas 5–4 wait control
A5WT1
A5WT0
EPSON
VI SDRAM CONTROLLER BLOCK: SDRAM INTERFACE
Setting
–
1 Used 0 Not used
1 Used 0 Not used
1 8 bits 0 16 bits
A14DF[1:0] Number of cycles
1 1 3.5
1 0 2.5
0 1 1.5
0 0 0.5
–
A14WT[2:0] Wait cycles
1 1 1 7
1 1 0 6
1 0 1 5
1 0 0 4
0 1 1 3
0 1 0 2
0 0 1 1
0 0 0 0
–
1 Used 0 Not used
1 Used 0 Not used
1 8 bits 0 16 bits
A8DF[1:0] Number of cycles
1 1 3.5
1 0 2.5
0 1 1.5
0 0 0.5
–
A8WT[2:0] Wait cycles
1 1 1 7
1 1 0 6
1 0 1 5
1 0 0 4
0 1 1 3
0 1 0 2
0 0 1 1
0 0 0 0
–
A6DF[1:0] Number of cycles
1 1 3.5
1 0 2.5
0 1 1.5
0 0 0.5
–
A6WT[2:0] Wait cycles
1 1 1 7
1 1 0 6
1 0 1 5
1 0 0 4
0 1 1 3
0 1 0 2
0 0 1 1
0 0 0 0
–
1 8 bits 0 16 bits
A5DF[1:0] Number of cycles
1 1 3.5
1 0 2.5
0 1 1.5
0 0 0.5
A5WT[2:0] Wait cycles
1 1 1 7
1 1 0 6
1 0 1 5
1 0 0 4
0 1 1 3
0 1 0 2
0 0 1 1
0 0 0 0
Init. R/W Remarks
– – 0 when being read.
0 R/W
0 R/W
0 R/W
1 R/W
1
– – 0 when being read.
1 R/W
1
1
– – 0 when being read.
0 R/W
0 R/W
0 R/W
1 R/W
1
– – 0 when being read.
1 R/W
1
1
– – 0 when being read.
1 R/W
1
– – 0 when being read.
1 R/W
1
1
– – 0 when being read.
0 R/W
1 R/W
1
– – 0 when being read.
1 R/W
1
1
