II-4 BCU (Bus Control Unit)
The BCU (Bus Control Unit) provides an interface for external devices and on-chip user logic block. The types
and sizes of memory and peripheral I/O devices can be set for each area of the memory map and can be controlled
directly by the BCU. This unit also supports a direct interface for DRAM and burst ROM. This chapter describes
how to control the external and internal system interface, and how it operates.
Note: The control registers of the external system interface shown in this chapter are mapped to the
internal 16-bit I/O area. Therefore, the addresses of these control registers are indicated by half-
word (16-bit) addresses unless otherwise specified. Note that the control registers can be
accessed in bytes, half-words, or words.
Pin Assignment for External System Interface
I/O Pin List
External I/O pins
Table 4.1 lists the pins used for the external system interface.
Pin name
A[0]/#BSL
A[10:1]/SDA[9:0]
A11
A[13:12]/SDA[12:11]
A[15:14]/SDBA[1:0]
A[23:16]
D[15:0]
#CE10EX/#CE9&10EX
#CE9/#CE17/#CE17&18
#CE8/#RAS1/#CE14/#RAS3/#SDCE1
#CE7/#RAS0/#CE13/#RAS2/#SDCE0
#CE6/#CE7&8
#CE5/#CE15/#CE15&16
#CE4/#CE11/#CE11&12
#RD
#EMEMRD
#WRL/#WR/#WE
#WRH/#BSH
#HCAS/#SDCAS
#LCAS/#SDRAS
BCLK/SDCLK
P35/#BUSACK/GPIO1
P34/#BUSREQ/#CE6/GPIO0
P33/#DMAACK1/SIN3/SDA10
P32/#DMAACK0/#SRDY3/HDQM
P31/#BUSGET/#GARD/GPIO2
P30/#WAIT/#CE4&5
P21/#DWE/#GAAS/#SDWE
P20/#DRD/SDCKE
P15/EXCL4/#DMAEND0/#SCLK3/LDQM
#X2SPD
EA10MD[1:0]
S1C33L03 FUNCTION PART
Table 4.1 I/O Pin List
I/O
O
Address bus (A0) / Bus strobe (Low-byte)
Address bus (A1–A10) / SDRAM address bus (SDA0–SDA9)
O
Address bus (A11)
O
Address bus (A12–A13) / SDRAM address bus (SDA11–SDA12)
O
Address bus (A14–A15) / SDRAM bank select (SDBA0–SDBA1)
O
O
Address bus (A16–A23)
I/O Data bus (D0–D15)
O
Area 10/(9&10) external memory chip enable
O
Area 9/17/(17&18) chip enable
O
Area 8/14 chip enable / DRAM Row strobe / SDRAM chip enable 1
O
Area 7/13 chip enable / DRAM Row strobe / SDRAM chip enable 0
O
Area 6/(7&8) chip enable
O
Area 5/15/(15&16) chip enable
O
Area 4/11/(11&12) chip enable
O
Read signal
O
Read signal for area 3/10 emulation mode
O
Write (Low-byte) / Write / DRAM write
O
Write (High-byte) / Bus strobe (High-byte)
O
DRAM column address strobe (High-byte) / SDRAM column address strobe
O
DRAM column address strobe (Low-byte) / SDRAM row address strobe
O
Bus clock output / SDRAM operating clock
I/O I/O port / Bus request acknowledge / LCDC general-purpose input/output
I/O I/O port / Bus release request / Area 6 chip enable / LCDC general-purpose
input/output
I/O I/O port / HSDMA Ch. 1 acknowledge output / Serial I/F Ch. 3 data input /
SDRAM address bus 10
I/O I/O port / HSDMA Ch. 0 acknowledge output / Serial I/F Ch. 3 ready signal output /
SDRAM data (high byte) input/output mask signal output
I/O I/O port / Bus status monitor signal output / Area read signal output for GA /
LCDC general-purpose input/output
I/O I/O port / Wait cycle request / Areas 4&5 chip enable
I/O I/O port / DRAM write (Low-byte) / Area address strobe output for GA / SDRAM write
I/O I/O port / DRAM read / SDRAM clock enable
I/O I/O port / 16-bit timer 4 event counter input / HSDMA Ch. 0 end-of-transfer signal
output / Serial I/F Ch. 3 clock input/output / SDRAM data (low byte) input/output mask
signal output
I
CPU - BCLK clock ratio
1: CPU clock = Bus clock, 0: CPU clock = Bus clock x 2
I
Area 10 boot mode selection
11: External ROM, 10: Internal ROM
EPSON
II CORE BLOCK: BCU (Bus Control Unit)
Function
A-1
B-II
BCU
B-II-4-1
