RCA1–RCA0: Column address size selection (D[B:A]) / Bus control register (0x4812E)
Select the column address size of DRAM.
The contents set here are applied to all of areas 14, 13, 8, and 7 that are set for DRAM.
RCA can be read to obtain its set value.
At cold start, RCA is set to "0" (8 bits). At hot start, RCA retain its status before being initialized.
RPC2: Refresh enable (D9) / Bus control register (0x4812E)
Control the DRAM refresh function.
Write "1": Enabled
Write "0": Disabled
Read: Valid
When DRAM is connected directly, a refresh cycle is generated by writing "1" to RPC2. The internal refresh
function is disabled by writing "0" to RPC2.
Since the BCU stops operating in the HALT2 and the SLEEP modes, no refresh cycle is generated regardless of
how this bit is set.
The contents set here are applied to all of areas 14, 13, 8, and 7 that are set for DRAM.
At cold start, RPC2 is set to "0" (disabled). At hot start, RPC2 retains its status before being initialized.
RPC1: Refresh method selection (D8) / Bus control register (0x4812E)
Select the DRAM refresh method.
Write "1": Self-refresh
Write "0": CAS-before-RAS refresh
Read: Valid
To perform a CAS-before-RAS refresh, set RPC1 to "0" and then RPC2 to "1". This causes the underflow output
signal of the 8-bit programmable timer 0 is fed to the DRAM interface, at which timing a refresh cycle is
generated.
To start a self-refresh, set RPC1 to "1" and then RPC2 to "1". The self-refresh is disabled by writing "0" to RPC2.
The contents set here are applied to all of areas 14, 13, 8, and 7 that are set for DRAM.
At cold start, RPC1 is set to "0" (CAS-before-RAS refresh). At hot start, RPC1 retains its status before being
initialized.
RPC0: Refresh RPC delay (D7) / Bus control register (0x4812E)
Set a RPC delay when at start of refresh.
Write "1": 2 cycles
Write "0": 1 cycle
Read: Valid
Set a time from the immediately preceding precharge to the falling transition of #HCAS/#LCAS necessary in order
to perform a refresh. This time is 2 cycles when RPC0 = "1" or 1 cycle when RPC0 = "0".
The contents set here are applied to all of areas 14, 13, 8, and 7 that are set for DRAM.
At cold start, RPC0 is set to "0" (1 cycle). At hot start, RPC0 retains its status before being initialized.
S1C33L03 FUNCTION PART
Table 4.26 Column Address Size
RCA1
RCA0
Column address size
1
1
11
1
0
10
0
1
9
0
0
8
EPSON
II CORE BLOCK: BCU (Bus Control Unit)
A-1
B-II
BCU
B-II-4-41
