Epson CMOS 32-Bit Single Chip Microcomputer S1C33L03 Technical Manual page 171

HEX Vector number
Exception/interrupt name
No. (Hex address)
38 56(Base+E0) Serial interface Ch.0
39 57(Base+E4)
3A 58(Base+E8)
59 reserved
3C 60(Base+F0) Serial interface Ch.1
3D 61(Base+F4)
3E 62(Base+F8)
63 reserved
40 64(Base+100) A/D converter
41 65(Base+104) Clock timer
66–67 reserved
44 68(Base+110) Port input interrupt 4
45 69(Base+114) Port input interrupt 5
46 70(Base+118) Port input interrupt 6
47 71(Base+11C) Port input interrupt 7
Base = Set value in the TTBR register (0x48134 to 0x48137); 0xC00000 by default.
S1C33L03 FUNCTION PART
II CORE BLOCK: CPU AND OPERATING MODE
Exception/interrupt factor
Receive error
Receive buffer full
Transmit buffer empty
–
Receive error
Receive buffer full
Transmit buffer empty
–
A/D converter, end of conversion
Falling edge of 32 Hz, 8 Hz, 2 Hz or 1 Hz signal
1-minuet, 1-hour or specified time count up
–
Edge (rising or falling) or level (High or Low)
Edge (rising or falling) or level (High or Low)
Edge (rising or falling) or level (High or Low)
Edge (rising or falling) or level (High or Low)
