Port Swapping
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
•
If you check the Active=Saved check box on any FICON VSAN, then the swapped configuration is
Tip
automatically saved to startup. Otherwise, you must explicitly save the running configuration
immediately after swapping the ports.
Once you swap ports, the switch automatically performs the following actions:
•
•
If you attempt to bring the port up, you must explicitly shut down the port to resume traffic.
To view the latest FICON information, you must click the Refresh button. See the
Note
Saving the Running Configuration" section on page
This section includes the following topics:
•
•

About Port Swapping

Be sure to follow these guidelines when using the FICON port swapping feature:
•
•
•
•
•
•
The 32-port module guidelines also apply for port swapping configurations .
Note
Cisco MDS 9000 Family Fabric Manager Configuration Guide
36-32
If you swap a port in a module that has unlimited oversubscription ratios enabled with a port in a
module that has limited oversubscription ratios, then you may experience a degradation in
bandwidth.
Shuts down both the old and new ports.
Swaps the port configuration.
About Port Swapping, page 36-32
Swapping Ports, page 36-33
Port swapping is not supported for logical ports (PortChannels, FCIP links). Neither the
old-port-number nor the new-port-number can be a logical port.
Port swapping is not supported between physical ports that are part of a PortChannel. Neither the
old-port-number nor the new-port-number can be a physical port that is part of a PortChannel.
Before performing a port swap, the Cisco NX-OS software performs a compatibility check. If the
two ports have incompatible configurations, the port swap is rejected with an appropriate reason
code. For example, if a port with BB_credits as 25 is being swapped with an OSM port for which a
maximum of 12 BB_credits is allowed (not a configurable parameter), the port swapping operation
is rejected.
Before performing a port swap, the Cisco NX-OS software performs a compatibility check to verify
the extended BB_credits configuration.
If ports have default values (for some incompatible parameters), then a port swap operation is
allowed and the ports retain their default values.
Port tracking information is not included in port swapping. This information must be configured
separately (see Chapter 65, "Configuring Port
Chapter 36
36-23.
Tracking").
OL-17256-03, Cisco MDS NX-OS Release 4.x
Configuring FICON
"Automatically
