Chapter 60 Monitoring Network Traffic Using SPAN
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Click Close in each of the three open dialog boxes.
Step 10

Deleting SPAN Sessions

To delete a SPAN session using Device Manager, follow these steps:
Choose Interface > SPAN.
Step 1
You see the SPAN dialog box.
Step 2 Click the Sessions tab.
Step 3 Click the SPAN session you want to delete.
Step 4 Click Delete.
The SPAN session is deleted.
Close the dialog box.
Step 5

SPAN Conversion Behavior

SPAN features (configured in any prior release) are converted as follows:
•
•
OL-17256-03, Cisco MDS NX-OS Release 4.x
If source interfaces and source VSANs are configured in a given session, then all the source VSANs
are removed from that session.
For example, before Cisco MDS SAN-OS Release 1.0(4):
Session 1 (active)
Destination is fc1/9
No session filters configured
Ingress (rx) sources are
vsans 10-11
fc1/3,
Egress (tx) sources are
fc1/3,
Once upgraded to Cisco MDS SAN-OS Release 1.1(1):
Session 1 (active)
Destination is fc1/9
No session filters configured
Ingress (rx) sources are
fc1/3,
Egress (tx) sources are
fc1/3,
Session 1 had both source interfaces and source VSANs before the upgrade. After the upgrade, the
source VSANs were removed (rule 1).
If interface level VSAN filters are configured in source interfaces, then the source interfaces are also
removed from the session. If this interface is configured in both directions, it is removed from both
directions.
For example, before Cisco MDS SAN-OS Release 1.0(4):
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Configuring SPAN
60-9
