Chapter 48 Configuring FCIP
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Figure 48-9
You see the switch selections as shown in
Figure 48-10
Choose the switches that act as endpoints for the FCIP link and click Next.
Step 2
Choose the Gigabit Ethernet ports on each switch that will form the FCIP link.
Step 3
If both Gigabit Ethernet ports are part of MPS-14/2 modules, check the Enforce IPSEC Security check
Step 4
box and set the IKE Auth Key, as shown in
on page 44-5
Check the Use Large MTU Size (Jumbo Frames) option to use jumbo size frames of 2300. Since Fibre
Channel frames are 2112, we recommended that you use this option. If you uncheck the box, the FCIP
Wizard does not set the MTU size, and the default value of 1500 is set.
Note
OL-17256-03, Cisco MDS NX-OS Release 4.x
FCIP Wizard
Switch Selections
for information on IPsec and IKE.
In Cisco MDS 9000 SAN-OS, Release 3.0(3), by default the Use Large MTU Size (Jumbo
Frames) option is not selected.
Figure 48-10.
Figure 48-11. See the "IPsec and IKE Terminology" section
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Using the FCIP Wizard
