iSCSI Authentication Setup Guidelines and Scenarios
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Select the General tab and select up from the Admin drop-down menu for the Gigabit Ethernet
e.
interface in slot 7 port 1.
f. Click the Apply Changes icon.
Note
Configure the iSCSI interface in slot 7 port 1 to identify all dynamic iSCSI initiators by their IP address,
Step 4
and enable the interface.
a. In Fabric Manager, choose Switches > Interfaces > FC Logical in the Physical Attributes pane.
Click the iSCSI tab in the Information pane.
b.
Select ipaddress from the Initiator ID Mode drop-down menu and click the Apply Changes icon.
c.
In Device Manager, choose Interfaces > Ethernet and iSCSI.
d.
Click the iSCSI tab.
e.
Select up from the Admin drop-down menu for the iSCSI interface in slot 7 port 1.
f.
Click Apply.
g.
Configure the Gigabit Ethernet interface in slot 7 port 5 with an IPv4 address and enable the interface.
Step 5
In Fabric Manager, choose Switches > Interfaces > Gigabit Ethernet in the Physical Attributes
a.
pane.
Click the IP Address tab in the Information pane and click Create Row.
b.
Set the IP address and subnet mask for the Gigabit Ethernet interface in slot 7 port 5.
c.
Click Create.
d.
Select the General tab and select up from the Admin drop-down menu for the Gigabit Ethernet
e.
interface in slot 7 port 5.
Click the Apply Changes icon.
f.
Configure the iSCSI interface in slot 7 port 5 to identify all dynamic iSCSI initiators by node name and
Step 6
enable the interface.
In Fabric Manager, choose Switches > Interfaces > FC Logical in the Physical Attributes pane.
a.
Click the iSCSI tab in the Information pane.
b.
Select name from the Initiator ID Mode drop-down menu and click the Apply Changes icon.
c.
In Device Manager, choose Interfaces > Ethernet and iSCSI.
d.
e. Click the iSCSI tab.
f. Select up from the Admin drop-down menu for the iSCSI interface in slot 7 port 5.
Click Apply.
g.
Note
Verify the available Fibre Channel targets.
Step 7
In Device Manager, Choose FC > Name Server.
a.
Click the General tab.
b.
Create a zone named iscsi-zone-1 with host 1 and one Fibre Channel target in it.
Step 8
Cisco MDS 9000 Family Fabric Manager Configuration Guide
50-60
Host 2 is connected to this port.
Host 1 is connected to this port.
Chapter 50 Configuring iSCSI
OL-17256-03, Cisco MDS NX-OS Release 4.x
