Chapter 55 Configuring SCSI Flow Services and Statistics
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
•
•
To take advantage of this feature, only the initiator must be directly attached to an SSM.
The SCSI flow statistics feature requires the Enterprise Package license installed only on the initiator
Note
switches.
For SCSI flow statistics, the initiator must connect to an SSM on a Cisco MDS switch while the target
Note
can connect to any other switch in the fabric. The SCSI flow initiator and target cannot connect to the
same switch.

Configuring SCSI Flow Statistics

This section includes the following topics:
•
•

Enabling SCSI Flow Statistics

To enable SCSI flow statistics monitoring using Fabric Manager, follow these steps:
Expand End Devices and then select SSM Features in the Physical Attributes pane.
Step 1
You see the FCWA tab in the Information pane.
Click Create Row in the Information pane to create a SCSI flow or click a row in the FCWA table to
Step 2
modify an existing SCSI flow.
You see the FC Write Acceleration dialog box shown in
Select the initiator and target WWNs and VSAN IDs and check the Enable Statistics check box to
Step 3
enable SCSI flow statistics on this SCSI flow.
OL-17256-03, Cisco MDS NX-OS Release 4.x
Maximum I/O response time
–
Other SCSI commands (not read or write)
Test unit ready
–
Report LUN
–
Inquiry
–
Read capacity
–
Mode sense
–
Request sense
–
Errors
Number of timeouts
–
Number of I/O failures
–
– Number of various SCSI status events
– Number of various SCSI sense key errors or events
Enabling SCSI Flow Statistics, page 55-7
Clearing SCSI Flow Statistics, page 55-8
Figure 55-5.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
SCSI Flow Statistics
55-7
