Chapter 62 Configuring Call Home
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Expand Switches, expand Events, and select Call Home in the Physical Attributes pane.
Step 1
Click the User Defined Command tab in the Information pane.
Step 2
You see the User Defined Command information shown in
Figure 62-7
Click the Create Row icon.
Step 3
Check the check boxes in front of the switches from which you want to receive alerts.
Step 4
Select the alert group type from the Alert Group Type drop-down list.
Step 5
Step 6 Select the ID (1-5) of the CLI command. The ID is used to keep track of the messages.
Step 7 Enter the CLI show command in the CLI Command field.
Step 8 Click Create.
Repeat Steps 3 through 7 for each command you want to associate with the profile.
Step 9
Click Close to close the dialog box.
Step 10

Call Home Message Level Feature

The Call Home message level feature allows you to filter messages based on their level of urgency. Each
destination profile (predefined and user-defined) is associated with a Call Home message level threshold.
Any message with a value lower than the urgency threshold is not sent. The urgency level ranges from 0
(lowest level of urgency) to 9 (highest level of urgency), and the default is 0 (all messages are sent).
Call Home severity levels are not the same as system message logging severity levels.
Note

Setting the Call Home Message Levels Using Fabric Manager

To set the message level for each destination profile for Call Home using Fabric Manager, follow these
steps:
In Fabric Manager, expand the Switches folder in the Physical Attributes pane, expand Events and then
Step 1
select Call Home.
You see the Call Home information in the Information pane.
OL-17256-03, Cisco MDS NX-OS Release 4.x
User Defined Command Dialog Box
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Call Home Message Level Feature
Figure 62-7.
62-11
