Chapter 30 Configuring and Managing Zones
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
An edit box appears around the zone or zone set name.
Enter a new name.
Step 5
Click Activate or Distribute.
Step 6

Cloning Zones, Zone Sets, FC Aliases, and Zone Attribute Groups

To clone a zone, zone set, fcalias, or zone attribute group, follow these steps:
Step 1 Choose Zone > Edit Local Full Zone Database.
You see the Select VSAN dialog box.
Step 2 Select a VSAN and click OK.
You see the Edit Local Full Zone Database dialog box for the selected VSAN.
Choose Edit > Clone.
Step 3
You see the Clone Zoneset dialog box shown in
followed by the original name.
Figure 30-36
Change the name for the cloned entry.
Step 4
Click OK to save the new clone.
Step 5
The cloned database now appears along with the original database.

Migrating a Non-MDS Database

To use the Zone Migration Wizard to migrate a non-MDS database using Fabric Manager, follow these
steps:
Step 1 Choose Zone > Migrate Non-MDS Database.
You see the Zone Migration Wizard.
Step 2 Follow the prompts in the wizard to migrate the database.
OL-17256-03, Cisco MDS NX-OS Release 4.x
Clone Zoneset Dialog Box
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Figure 30-36. The default name is the word Clone
Zone Set Duplication
30-35
