CFS Example Using Fabric Manager
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Figure 13-19
From the Config Action drop-down list, select abortChanges for each switch that you enabled for CFS
Step 12
(see
Figure 13-20
Note
Step 13 Click the Apply Changes icon to commit the configuration changes for that feature and distribute the
changes through CFS.
When using CFS with features such as DPVM and device alias, you must select commit at the end of
Note
each configuration. If the session is locked, you must exit the feature by selecting abort.
To configure the master or seed switch for distribution for each feature using Fabric Manager, follow
these steps:
Choose the feature that needs a merge master for CFS. For example, expand Switches, expand Events
Step 1
and select CallHome from the Physical Attributes pane.
The Information pane shows that feature including a CFS tab.
Click the CFS tab to display the CFS state for each switch in the fabric for that feature.
Step 2
Check the Master column check box for the switch to act as the merge master for this feature.
Step 3
Click the Apply Changes icon to select this switch as master for future CFS distributions.
Step 4
.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
13-22
Status Change to Running
Figure 13-20).
Commit Configuration Changes
Fabric Manager does not change the status to pending if enable is selected, because the pending
status does not apply until the first actual change is made.
Chapter 13 Using the CFS Infrastructure
OL-17256-03, Cisco MDS NX-OS Release 4.x
