Enabling 32-Bit and 64-Bit Alarms

S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Click Create.
Step 7
Confirm the operation to define an alarm and a log event when the system prompts you to define a
Step 8
severity event. If you do not confirm the operation, the system only defines a log event.
Click More then click the Alarms tab from the Threshold Manager dialog box to verify the alarm you
Step 9
created.
Step 10 Close both dialog box pop-ups.
Enabling 32-Bit and 64-Bit Alarms
To configure an RMON alarm for one or more ports using Device Manager, follow these steps:
Choose Admin > Events > Threshold Manager and click the FC Interfaces > Create tab.
Step 1
You see the create 32-bit and 64-bit alarm dialog box shown in
Figure 59-2
Cisco MDS 9000 Family Fabric Manager Configuration Guide
59-4
Create 32 and 64-Bit Dialog Box
Chapter 59 Configuring RMON
Figure 59-2.
OL-17256-03, Cisco MDS NX-OS Release 4.x
