Chapter 50 Configuring iSCSI
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Figure 50-40
iSCSI
HBA
iqn.host-1
iSCSI
HBA
iqn.host-1
In Figure
When the Gigabit Ethernet interface of the VRRP master fails, the iSCSI session is terminated. The host
then reconnects to the target and the session comes up because the second Gigabit Ethernet interface has
taken over the virtual IP address as the new master.

Ethernet PortChannel-Based High Availability

All iSCSI data traffic for one iSCSI link is carried on one TCP connection. Consequently, the aggregated
Note
bandwidth is 1 Gbps for that iSCSI link.
Figure 50-41
OL-17256-03, Cisco MDS NX-OS Release 4.x
VRRP-Based iSCSI High Availability
Physical view (iSCSI)
VRRP across two ports
IP
network
Logical view
Virtual IP-10.1.1.1
IP
network
50-40, each iSCSI host discovers one iSCSI target for every physical Fibre Channel target.
provides a sample Ethernet PortChannel-based high availability iSCSI configuration.
Virtual IP-10.1.1.1
lqn.com.cisco.mds.vr1.gw.p1
lqn.com.cisco.mds.vr1.gw.p1
Cisco MDS 9000 Family Fabric Manager Configuration Guide
iSCSI High Availability
FC
FC fabric
pWWN-P1
FC
FC
50-55
