Click the Card Module Config tab.
Step 3
Select off from the drop-down list in the row for the module(s) you want to power off.
Step 4
Click the Apply Changes icon.
Step 5
Note

Identifying Module LEDs

Table 19-5
Table 19-5
LED
Status
Speed
Link
OL-17256-03, Cisco MDS NX-OS Release 4.x
To power on a module, repeat Steps 1-4 but select on in Step 3.
describes the LEDs for the Cisco MDS 9200 Series integrated supervisor modules.
LEDs for the Cisco MDS 9200 Series Supervisor Modules
Status Description
Green All diagnostics pass. The module is operational (normal initialization sequence).
Orange One of the following applies:
The module is booting or running diagnostics (normal initialization sequence).
The inlet air temperature of the system has exceeded the maximum system
operating temperature limit (a minor environmental warning). To ensure
maximum product life, you should immediately correct the environmental
temperature and restore the system to normal operation.
Red One of the following applies:
The diagnostic test failed. The module is not operational because a fault occurred
during the initialization sequence.
he inlet air temperature of the system has exceeded the safe operating
T
temperature limits of the card (a major environmental warning). The card has
been shut down to prevent permanent damage. The system will be shut down
after two minutes if this condition is not cleared.
On 2-Gbps mode and beacon mode disabled.
Off 1-Gbps mode and beacon mode disabled.
Flashing Beacon mode enabledSee the
page 20-19.
Solid green Link is up.
Solid Link is disabled by software.
yellow
Flashing A fault condition exists.
yellow
Off No link.
"Identifying the Beacon LEDs" section on
Cisco MDS 9000 Family Fabric Manager Configuration Guide
