System Message Logging Configuration
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Most tabs in the Information pane for features using CFS are dimmed until you click the CFS tab. The
Note
CFS tab shows which switches have CFS enabled and shows the master switch for this feature. Once the
CFS tab is click, the other tabs in the Information pane that use CFS are activated.
You can configure a maximum of three syslog servers. One of these syslog servers should be Fabric
Manager if you want to view system messages from the Event tab in Fabric Manager.
To configure system message logging servers, follow these steps:
In Fabric Manager, expand Switches, expand Events and select SysLog in the Physical Attributes pane,
Step 1
then click the Servers tab in the Information pane.
Figure 61-6
In Device Manager, choose Logs > Syslog > Setup and click the Servers tab in the Syslog dialog box.
Figure 61-7
Click the Create Row icon in Fabric Manager, or click Create in Device Manager (see
Step 2
add a new syslog server.
Enter the name or IP address in dotted decimal notation (for example, 192.168.2.12) of the syslog server
Step 3
in the Name or IP Address field.
Step 4 Set the message severity threshold by clicking the MsgSeverity radio button and set the facility by
clicking the Facility radio button.
Step 5 Click the Apply Changes icon in Fabric Manager, or click Create in Device Manager to save and apply
your changes.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
61-8
Servers Tab in Fabric Manager Syslog
Servers Tab in Device Manager Syslog
Chapter 61 Configuring System Message Logging
OL-17256-03, Cisco MDS NX-OS Release 4.x
Figure 61-7) to
