5.2.3 Menu Options
On the bottom of the screen there are four menus accessible via the function
keys.

accesses the tuning menu and allows selecting the channel plan.

the signal parameters.


In the Advanced menu there are some options to set the constellation tool.
They are:
Grid type:

•Full Grid:The grid where the constellation is displayed is a complete grid.
•Cross Grid: The grid where the constellation is displayed is made of
crosses.
Persistence: It allows the user to set the level of persistence, which is the

lapse of time the signal stays on the screen before disappearing. Available
options according to the persistence level are: low, medium, high or
permanent.
Zoom: It allows the user to select a quarter (I, II, III or IV) where apply

the zoom in. To come back to normal view select All.
Start Carrier/Stop Carrier: This option allows selecting the range of

carriers to be displayed between the first and last.
Clear: This option clears all symbols in the whole constellation window.

Chapter 5: TOOLS
It displays the channel / frequency where is pointing the cursor,
It displays the selected transmission standard menu and accesses
It displays the Tools menu.
It displays the Advanced menu.
