4 MER and C/N measurement over time (span time is set in configuration). In
case of monitoring a FM signal, it shows nothing as there is no measure to
draw.
5 Indicator of Signal coverage started.
6 LNB, Selected band; battery level.
7 Signal information window 1:
•Frequency: frequency at which signal is locked; Profile (only for
DVB-T2 signals): Base or Lite; PLP identifier (only for DVB-T2 signals):
identifier of the layer being measured, TS Hierarchy (table hierarchy at
the transport stream) TS Priority (packet priority at the transport
stream).
8 Signal information window 2:
•Measurement over time.
9 Signal information window 3:
File name: Name of current coverage file.

Elapsed: Time elapsed since the beginning of the coverage study.

Samples: Samples taken since the beginning of the coverage study.

Space left: Space left in the memory to save data.

GPS status: It shows if the GPS receiver is locked or unlocked.

Latitude, Longitude: It shows the latitude and longitude at the current

position, if GPS is locked.
10 Channels from the channel plan being monitored. Measurement data are
from the selected channel (pointed by a red arrowhead).
Cursor functions:
•No function for this tool.
Axis Description (Single Channel Monitoring screen):
•Axis X: Window 1: Frequency; Window 2 and 3: Time.
•Axis Y: Window 1 and 2: Power; Window 3: MER and C/N.
5.10.3 Menu Options
At the bottom of the screen there are four menus available via the function keys.

access the tuning menu.

the signal parameters.
Chapter 5: TOOLS
It displays the channel/frequency where is pointing the cursor and
It displays the selected transmission standard menu and accesses
