PID List: It shows an ordered PID list with a short explanation of its
contents. PID bitrate is refreshed continuously to help in understand
bandwidth usage.
5.17.2
Operation
The Transport Streams (TS) Analyzer tool is available for all DIGITAL signals.
1
Connect the digital signal to any input of the equipment.
2
Select the channel or frequency and tune the signal.
3
Press the Tools key
4
Select the TS Analyzer option.
5
A drop down menu appears with these options: Tables, Bitrates, Alarms,
PID list and T2MI. Select your option.
6
While starting, the TS Analyzer takes few seconds to detect and identify the
TS signal (it shows the table capture process on screen), and then the results
appear.
7
An error message pops up if the signal does not contain any TS or if the TS
cannot be found. In this case, check the signal. If the user cancels the table
capture process, no data about the TS will appear. Then select "Restart
analysis" on F4 to try capture the TS again.
The following describes in detail each one of these functions.
5.17.3
Table Analyzer
Description
►
This function displays the TS tables. When system starts it shows the table
capture process. When it finishes tables are shown in a tree diagram for easy
browsing with the keyboard. All components and contents of tables can be
consulted by deploying the nodes. So the user can analyse the tables and see in
detail what is being transmitted and if the information is properly encapsulated.
This tool requires detailed knowledge about the contents of these tables.
March 2025
.
151
Chapter 5: TOOLS
