7
Ethernet connector for NetUpdate / Streaming VA / webControl.
8
USB Connector.
9
HDMI™ Output.
10
Video / Audio Input.
11
Access to Service Mode Button.
12
RF Input Connector.
2.2.2
PROWATCH Neo 2
from left to right:
1
Status LED:
Colour GREEN: In Operation.
Colour GREEN (blinking): Monitoring Enabled.
Colour ORANGE: Service Mode.
Colour ORANGE (blinking): Updating.
Colour RED: Error.
2
Input connector for CAM module.
March 2025
Figura 4. Front View.
Figure 5. Rear View.
5
Chapter 2: SETTING UP
