v 8 or 16 INPUTS OPTION
This annex contains operating instructions for the next options:
OP-00x-PN-8: 8 RF inputs without redundant power source.

OP-00x-PN-R: 8 RF inputs with redundant power source.

OP-00x-PN-16: 16 RF inputs (redundant power source included).

The standard
you can expand RF inputs to 8 or 16. This option should be asked when
requesting the equipment.
v.1 Single Signal Operation
1 Connect each signal to the corresponding RF input.
2 The RF1 input is selected by default.
3 To change the default input open the webControl and go to "Measurements
and Spectrum" or "TV Parameters" then go to option "Config" and select
other input.
4 The equipment only can work with the signal from the selected input.
v.2 Multiple Signal Operation
1 The "Mask Monitoring" tool allows you to work sequentially (almost
simultaneously) with several or all inputs from RF1 to RF8 or RF16. This is
an optional tool (for more details refer to
2 Mask Monitoring settings, management and historical record search is done
through the webControl software (for more details refer to
on page
3 During monitoring configuration, you can individually select and configure
each available input (1-8 or 1-16 according to option) with the condition that
all them must be on the same frequency band: terrestrial (from 5 to 1000
MHz) or satellite (from 950 to 2500 MHz). It also allows you to select a
different detection type for each input.
Annex v: 8 or 16 INPUTS OPTION
Neo
PROWATCH
204).
equipment has only 1 input. With this option
"Mask Monitoring" on page
320
228).
