► Screen Description
1
Selected function (Console).
2
Selected installation and current date and hour
3
Access to settings:
•Change Password: It allows you to change your password.
•Reboot Equipment: It allows you to reset your equipment after
confirmation.
•About Equipment: It gives information about your equipment: model
name, serial number, release version / webControl version.
•Logout: It exits your current session.
4
Start / Stop console emulation button.
5
Joystick. Click left, right, up or down to simulate joystick movement. Click on
centre to simulate enter. You can use the joystick to move along the menus
and to select options. Also you can use your mouse pointer like a finger touch
on screen.
6
Direct Access keys to access Installation management and Settings. Press for
more than one second to access Preferences and Video / Audio settings.
7
Direct Access keys to access Measurement, Spectrum and TV mode.
8
Direct Access key to Screenshot (screenshot is saved on your remote device
and data on the equipment).
9
Softkeys or Function keys.
*. In case you have the GPS option installed, then it also appears current geographic coordinates.
March 2025
Figure 133.
213
*
.
Chapter 10: WEBCONTROL
