Promax PROWATCH Neo + Manual page 209

to the selected satellite channel plan from the list of diseqc programs
available for the current installation.
•Open File: This options appears if the file type selected is datalogger, data
capture or signal monitoring. In case of datalogger it opens the data
viewer. In case of data capture (if the capture was done in the Spectrum
Analyzer mode) shows the spectrum reference. In case of signal
monitoring it opens the signal monitoring viewer.
To get out from the Installation manager press any key to access
MEASUREMENT, SPECTRUM or TV mode.
9.4 New Installation
In the list of installations, when selecting the option Create New
installation wizard that helps to create a new installation.
1 During the process, the user has the option to edit the default name assigned
or import data from another installation.
2 The user can select the channel plans (terrestrial and satellite) that will be
used in that installation. At least one for each band has to be selected.
3 For satellite channel plans the user can select the Diseqc commands
associated to the installation and also the satellite band (Ku-Ka or C band)
and the frequencies of the LNB Oscillator.
4 During the creation process the softkeys functions are: Next (it goes to the
next step), Previous (it goes to the previous step) or Cancel (it cancels the
process).
5 When finish, the new installation created will be the current installation.
9.5 Tools
In the list of installations, when pressing the Tools
with some options to edit the installation files:
Mark All: It selects all installations in the list of installations.

Unmark All: It deselects all installations in the list of installations.

Archive: It compresses (using the ZIP algorithm) the selected installations

to save more space. A zipped installation shows a box icon
side in the list of installations. A zipped installation can be loaded as
anyone else, but the load time can be slightly higher because previously it
is unzipped automatically. Once the installation is unzipped the user must
March 2025 201 Chapter 9: INSTALLATIONS MANAGEMENT
it runs the
option it shows a menu
at the left
